CAT 315 Part Manual Page 672

Part Manual
HYDRAULIC SYSTEM
266-8046 MOTOR
GP-SWING
S/N: CJN1 -UP
PART OF 267-677
9 DRIVE GP-SWING
AN ATTACHMENT
SMCS-5058 i03245932
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 099-0320 1 BUSHING
J2 1 099-0321 1 SEAL-LIP TYPE
31 099-0322 1 BEARING-ROLLE
R
41 7I-0057 1 SPRING
51 099-4749 1 PLATE-CAM
61 7I-0058 1 PLATE-RETAINER
71 200-3335 1 PISTON AS
81 099-6530 3 PLATE-FRICTION
91 099-6531 3 PLATE-SEPARATOR
J10 1 099-6532 1 SEAL-O-RING
11 1 099-6535 1 PISTON-BRAKE
J12 1 6F-4718 2 SEAL-O-RING
13 1 099-0328 16 SPRING
14 1 099-0329 2 PIN
15 1 099-0330 4 SPRING
16 1 099-0331 4 RING
17 1 099-0332 4 BUSHING
18 1 099-0333 1 PLATE-VALVE
19 1 099-0334 1 BEARING AS-NEEDLE
20 1 099-0335 1 RING-RETAINING
21 1 123-2143 1 BARREL AS
22 1 209-6012 1 HOUSING
23 1 200-3338 1 BUSHING
24 1 7I-0060 2 PLUG
J25 1 095-1784 2 RING-BACKUP
J26 1 095-1585 2 SEAL-O-RING
J27 1 095-1580 2 SEAL-O-RING
28 1 7I-0061 2 VALVE (CROSSOVER RELIEF)
29 1 7I-0062 2 SPRING
30 1 7I-0063 2 SLEEVE AS
31 1 274-2565 1 HEAD
J32 1 095-1594 4 SEAL-O-RING
J33 1 3J-1907 3 SEAL-O-RING
34 1 9S-4191 3 PLUG-O-RING
35 1 229-0993 2 VALVE GP-RELIEF (SWING)
(EACH INCLUDES)
1 095-1594 1 SEAL-O-RING
M36 1 8T-0347 4 BOLT-SOCKET HEAD (M14X1.5X45-MM)
37 1 096-5933 2 VALVE-CHECK (MAKEUP)
J38 1 095-1789 2 RING
39 1 096-5934 2 SPRING
40 1 096-5932 2 PLUG
AVAILABLE REPAIR KIT(S
):
J 123-2145 1 KIT-SEAL (SWING MOTOR)
J-KIT MARKED J SERVICES PART(S) MARKED J
M-METRIC PART
642 HYDRAULIC SYSTEM 1of2 SEBP 4861-02
