OPERATOR STATION

316-8811 AIR CO

NDITIONER GP

S/N: CJN1 -UP

PART OF 235-900

4 AIR CONDITIONER & MOUNTING GP, 22 9-9084 HEATER & MTG GP-CAB

AN ATTACHMENT

SMCS-7320 i03012140

NOTE

REF

GRAPHIC

REF PART NUM BER QTY

PART NAM E

123456(PRODUCT LEVEL

)

SEE

PAGE

11 185-8300 35 SCREW-TAPPING

22 185-8302 3 SCREW AS-TAPPING

31 245-7817 2 MOTOR AS

41 245-7818 3CLIP

52 245-7819 2CLIP

61 245-7820 1 COVER-FRONT

71 245-7825 1 INSULATOR

82 245-7826 1 INSULATOR

92 245-7827 1 INSULATOR

10 2 245-7828 1 INSULATOR

11 1 245-7829 1 PACKING

12 1 245-7830 1CLIP

13 1 245-7831 1 SENSOR AS-TEMPERATURE (COOLANT)

14 1 245-7832 1 CONTROL AS

15 1 245-7833 1 CORE AS-HEATER

16 1 245-7834 1 DAMPER AS

17 2 245-7835 1 SENSOR AS (AMBIENT AIR TEMP)

Y18 2 245-7836 1 COIL GP-EVAPORATO

886

19 2 245-7838 1 PACKING

20 2 245-7839 1 MOTOR AS (WITH FAN)

Y21 1 245-7846 1 CONTROL GP-HEAT & A

IR COND (AIR INLET)

911

22 1 245-7847 1 HARNESS AS-HEATER & AIR COND

23 2 245-7856 3 SCREW AS-TAPPING

24 1 293-1137 1 FILTER GP-AIR (AIR C

ONDITIONER)

1 245-7823 1 FILTER ELEMENT-CAB AIR (AIR CONDITIONER)

1 245-7824 1 PACKING

25 2 316-8845 1 PLATE

26 2 316-8846 1 PLATE

27 2 316-8847 2ROD

28 2 316-8848 1ROD

29 1 316-8849 1ROD

30 2 316-8850 1ROD

Y-SEPARATE ILLUSTRATI

SEBP4861-02 1of3 OPER ATOR STATION 851
