CAT 315 Part Manual Page 217

Part Manual
ELECTRICAL AND STARTING SYSTEM
251-0544 PANEL
GP-SWITCH
–ENGINE SPEED, START
S/N: CJN1 -UP
PART OF 227-758
1 INSTALLATION GP-SECURITY
AN ATTACHMENT
TYPE 1
SMCS-1408, 1429, 7332, 7451 i02742288
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 3S-2093 5 STRAP-CABLE
Y2 1 9G-7641 1 SWITCH GP-START (ENGINE, KEY) 207
Y3 1 106-0107 1 SWITCH GP-ROTA
RY (THROTTLE POSITION)
205
41 185-9208 1KNOBAS
51 205-0826 1 FILM-INSTRUCTION (MACHINE SECURITY, CONSOLE)
61 205-8257 1 COIL AS (EXCITER
)
1 186-3735 2 PIN-CONNECTOR (16-GA TO 18-GA)
71 234-1156 1 COVER
81 267-7977 1 PANEL
91 251-0543 1 HARNESS AS-CONSOLE (RH)
1 102-8802 1 KIT-RECEPTACLE (2-PIN)
(INCLUDES RECEPTA
CLEAS&WEDGE)
1 155-2270 1 KIT-CONNECTING PLUG (2-PIN)
1 155-2274 1 KIT-CONNECTING PLUG (6-PIN)
(EACH PLUG KIT INCL
UDES PLUG AS, WEDGE &
INTERFACE SEAL)
10 1 096-6166 4 WASHER-HARD (4.5X9X1-MM THK)
11 1 119-5026 4 SCREW-PAN HEAD (10-16X0.63-IN)
M12 1 6V-9491 4 SCREW-MACHINE (M4
X0.7X20-MM)
M-METRIC PART
Y-SEPARATE ILLUSTRATION
SEBP4861-02 1of2 ELECTRICAL AND STARTING SYSTEM 187
