CAT 315 Part Manual Page 557

Part Manual
HYDRAULIC SYSTEM
275-1696 LINES GP-FRONT (contd. ) i03001047
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
2 6V-8641 1 CONNECTOR
C31 2 148-8336 1 CONNECTOR AS
2 3J-1907 1 SEAL-O-RING
2 6V-8397 1 SEAL-O-RING
2 6V-8636 1 CONNECTOR
32 2 148-8353 2 ELBOW AS
(EACH INCLUDES)
2 3J-1907 1 SEAL-O-RING
2 6V-8397 1 SEAL-O-RING
2 6V-9001 1 ELBOW
33 2 148-8367 1 ELBOW AS
2 6V-8397 1 SEAL-O-RING
2 6V-9850 1 ELBOW
C341,2 148-8378 2 ELBOW AS
(EACH INCLUDES)
1,2 3J-1907 1 SEAL-O-RING
1,2 6V-8397 1 SEAL-O-RING
1,2 6V-8724 1 ELBOW
35 1 148-8419 2 REDUCER AS
(EACH INCLUDES)
1 4J-5477 1 SEAL-O-RING
1 6V-8935 1 REDUCER-O-RING
36 2 148-8435 1TEEAS
2 3J-1907 1 SEAL-O-RING
2 6V-8397 2 SEAL-O-RING
2 6V-8781 1 TEE-FACE SEAL
37 2 148-8439 2TEEAS
(EACH INCLUDES)
2 3J-1907 1 SEAL-O-RING
2 6V-8397 2 SEAL-O-RING
2 6V-8774 1TEE
38 2 150-3036 1 ELBOW AS
2 3J-1907 1 SEAL-O-RING
2 6V-8397 1 SEAL-O-RING
2 8T-1905 1 ELBOW
39 2 153-6249 1 CONNECTOR AS
2 3J-1907 1 SEAL-O-RING
2 6V-8397 1 SEAL-O-RING
2 8T-8887 1 CONNECTOR
40 2 164-5567 3 COUPLER AS-QUICK DISCONNECT
(EACH INCLUDES)
2 3J-1907 1 SEAL-O-RING
2 6V-3965 1 FITTING (QUICK DISCONNECT)
41 2 164-9869 1 CONNECTOR AS
2 3J-1907 1 SEAL-O-RING
2 6V-8397 1 SEAL-O-RING
2 9X-2297 1 CONNECTOR
42 2 3J-1907 1 SEAL-O-RING
43 2 5K-5338 1CLIP
44 2 6V-8397 1 SEAL-O-RING
45 2 8T-4121 6 WASHER-HARD (11X21X2.5-MM THK)
M46 2 8T-4136 2 BOLT (M10X1.5X25-MM)
M47 2 8T-4137 3 BOLT (M10X1.5X20-MM)
M48 2 8T-4178 1 BOLT (M10X1.5X90-MM)
49 2 8T-4223 3 WASHER-HARD (13.5X25.5X3-MM THK)
M50 2 8T-4910 3 BOLT (M12X1.75X60-MM)
51 2 9M-8406 1CLIP
52 1 9X-6582 2 NUT (13/16-16-THD)
J53 2 148-8367 1 ELBOW AS
SEBP4861-02 2of4 HYDRAULIC SYSTEM 527
