CAT 315 Part Manual Page 965

Part Manual
OPERATOR STATION
176-1964 DOOR G
P-CAB
S/N: CJN1 -UP
PART OF 229-910
1 CAB GP, 189-2793 DOOR GP-CAB
AN ATTACHMENT
TYPE 2
SMCS-7308 i03172900
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
C1 2 327-6579 1 HANDLE-PULL
Y3 1 151-6792 1 WINDOW GP-DOOR 1068
41 156-6598 1HOOK
J5 2 156-6600 1LOCKAS
2 164-0514 1 CLIP
5A 2 164-0519 1 CLIP
61 156-6643 1 COVER
71 156-6645 1 HANDLE AS
7A 1 201-4391 1 CLIP
82 161-3639 1 HANDLE AS
92 161-3650 1 COVER AS
10 2 161-3663 1SEALAS
2 151-9497 45 CLIP
11 2 161-3665 1SEAL
12 2 259-7354 1 COVER
13 1 164-0515 1 JOINT
14 1 167-7038 1 GLASS
15 2 167-7039 1 GROMMET
M16 2 185-8180 3 SCREW (M6X1X16-MM)
17 1 8T-4224 2 WASHER-HARD (8.8X16X2-MM THK)
M18 2 096-2622 2 SCREW-MACHINE (M4
X0.7X8-MM)
M19 2 096-3884 2 NUT-SPRING
M20 2 101-8899 1 SCREW AS (M6X1X16-MM)
M21 2 101-8900 2 SCREW AS (M6X1X20-M
M)
22 1 151-9461 4 SPACER
23 1 156-6644 1 COVER
24 1 178-5573 4 SPACER
25 1 178-5574 2 SPACER
26 2 189-2690 1 HANDLE AS
27 2 4I-4286 1KNOB
M28 2 9X-2042 8 SCREW-TRUSS HEAD (M6X1X12-MM)
C-CHANGE FROM PREVIOUS TYPE
J-REQUIRES CORPORATE KEY
M-METRIC PART
Y-SEPARATE ILLUSTRATION
SEBP4861-02 1of3 OPER ATOR STATION 935
