CAT 315 Part Manual Page 246

Part Manual
ELECTRICAL AND STARTING SYSTEM
259-5161 WIRIN
G GP-CA B
S/N: CJN1 -UP
PART OF 259-719
3 OPERATOR AR
SMCS-1408, 7301 i02853579
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
13,4 3S-2093 10 STRAP-CABLE
24 7Y-5505 2 SPEAKER AS
(EACH INCLUDES)
4 7Y-3951 2 TERMINAL (FEMALE)
4 7Y-3954 1 CONNECTOR-PLUG
33 9W-0335 1 LIGHTER AS-CIGAR (24-VOLT)
–OR–
F 238-2318 1 LIGHTER AS-CIGAR (24-VOLT)
43 094-2080 1 SWITCH-MAGNETIC (24-VOLT) (START RELAY)
M5 4 099-7127 8 SCREW-MACHINE (M4X0.7X12-MM)
61 102-8016 1 RESISTOR AS
73 113-8490 20 FUSE (10-AMPERE)
83 113-8491 5 FUSE (15-AMPERE)
93 113-8492 3 FUSE (20-AMPERE)
10 3 113-8493 3 FUSE (25-AMPERE)
11 4 116-0210 4 BRACKET AS
12 3 124-3548 2 FUSE (30-AMPERE)
Y13 4 132-1829 1 ALARM GP (24-VOLT) 123
14 3 141-2759 7 FUSE (5-AMPERE)
15 3 161-3128 1 RELAY (24-VOLT) (BOOM FLOODLIGHT)
15A 3 161-3128 1 RELAY (24-VOLT) (CHASSIS LIGHT)
15B 3 161-3128 1 RELAY (24-VOLT) (CAB FLOODLIGHT)
15C 3 161-3128 1 RELAY (24-VOLT) (HORN)
15D 3 161-3128 1 RELAY (24-VOLT) (NEUTRAL START)
15E 3 161-3128 1 RELAY (24-VOLT) (TRAVEL ALARM)
16 4 268-1964 1 KIT-SERVICE METER
(INCLUDES FILM & METER)
17 4 163-6758 1 WIRE AS
18 2,3,4 163-6795 15 STRAP-CABLE
19 3 167-3593 1 STRAP
20 3 170-6888 1 PULLER-FUSE
21 4 213-0772 1 SWITCH AS-MAGNETIC (24-VOLT) (MAIN RELAY)
22 3 227-7575 1 PANEL-CONTROL (SWITCH)
23 3 234-1097 1 BRACKET
24 3 238-2212 1 SWITCH AS-ROCKER (FINE SWING)
3 167-3542 1 CONNECTOR-RECEPTACLE
3 167-3543 5 TERMINAL (MALE)
26 4 238-2390 1 CABLE AS
4 3T-4004 1 TERMINAL-SOLDER
E4125-7876 TUBE-HEAT SHRINK (17.78-MM DIA) (4-CM)
27 4 238-2391 1 CABLE AS
4 9G-4343 1 TERMINAL (4-GA)
E4125-7876 TUBE-HEAT SHRINK (17.78-MM DIA) (4-CM)
28 2 245-7760 8 INSULATION
29 2 251-0637 1 INSULATION
30 2 259-4883 1 ANTENNA AS
31 3 259-5290 1 BRACKET AS
32 1 259-5296 1 HARNESS AS-CAB
1 7Y-3952 4 CONNECTOR-PLUG
1 7Y-3958 2 CONNECTOR-PLUG
1 102-7964 2 CONNECTOR-PLUG
1 111-4816 1 CONNECTOR-PLUG
1 163-6659 1 CONNECTOR-PLUG
1 163-6699 1 CONNECTOR-PLUG
1 163-6803 9 CONNECTOR-PLUG
1 7Y-3955 2 CONNECTOR-RECEPTACLE
216 ELECTRIC AL AND S TARTING SY STEM 1of6 SEBP 4861-02
