INDEX

Name Page Name Page

STICK AR-HOE–

REACH,ACCUGRADEREADY.............. 770

STICKAR-REACH............................ 771

STICKGP-HOE............................... 772

773

774

775

776

777

778

779

783

785

STICKGP-HOE–ACCUGRADEREADY......... 780

781

STICK GP-HOE–

AUXILIARY,QUICKCPLR,REACH.......... 784

STORAGEGP-VANDALISMGUARD........... 346

STRAINERAS-FUEL(FLOATGAUGE)......... 104

106

108

110

113

115

118

120

SUNVISOR..................................1053

SUPPORTAS-ENCLOSURE................... 347

348

349

350

351

SUPPORTGP-SEAT..........................1045

SUSPENSIONGP-SEAT.......................1041

1042

1043

1044

1046

1048

1049

1050

1051

1052

SUSPENSIONGP-SEAT–AIR..................1047

SWITCH(LIQUIDLEVEL)(FUEL).............. 204

SWITCH(WINDOWLOWERLIMIT)............1059

SWITCHAS(FILTERBYPASS)................ 443

SWITCHAS-FOOT(WORKTOOL)............. 904

SWITCHAS-LIMIT(HYDRAULICLOCKOUT).... 203

SWITCH AS-LIQUID LEVEL (ENGINE OIL) . . . . . . 33

SWITCH AS-LIQUID LEVEL

(FUELTANKSHUTOFF).................... 96

SWITCH AS-LIQUID LEVEL

(HYDRAULICTANK)........................ 666

SWITCH AS-MAGNETIC (24-VOLT)

(AIRINLETHEATERRELAY)................ 251

SWITCH AS-MAGNETIC (24-VOLT)

(MAINRELAY).............................. 216

SWITCH AS-PRESSURE (HYDRAULIC OIL) . . . . 666

SWITCHAS-PRESSURE(IMPLEMENT)........ 551

555

SWITCH AS-PRESSURE

(IMPLEMENT,SWING)...................... 547

SWITCH AS-PRESSURE (PILOT, BOOM UP) . . . 562

564

590

597

604

SWITCH AS-PRESSURE (REFRIGERANT) . . . . . 990

SWITCHAS-PRESSURE(SWING)............. 574

SWITCHAS-PUSHBUTTON(HORN)........... 905

SWITCH AS-PUSH BUTTON

(MANUALLOWIDLE)....................... 906

SWITCHAS-ROCKER(FINESWING).......... 216

245

SWITCHAS-ROCKER(HEATEDSEAT)........1036

1040

SWITCHAS-ROCKER(LEVELING)............ 217

SWITCH AS-ROCKER (LOWER WASHER) . . . . . 209

SWITCH AS-ROCKER

(OVERLOADWARNING).................... 257

258

SWITCHAS-ROCKER(RADIOMUTE).......... 982

984

SWITCH AS-ROCKER (WIPER, LOWER ) . . . . . . . 209

SWITCH AS-ROLLER

(LOWER WASHER/WIPER, DISABLE) . . . . . . . 1073

SWITCH AS-TOGGLE

(ACCUGRADE BACKUP) . . ................. 225

SWITCH AS-TOGGLE

(AUTO/MANUAL ENG SPEED CONTROL) . . . 237

SWITCH AS-TOGGLE

(MANUALENGINESPEEDCONTROL)...... 237

SWITCH AS-TOGGLE (QUICK COUPLER) . . . . . . 208

223

SWITCH AS-TOGGLE

(SECONDARYSHUTDOWN)................ 260

SWITCH AS-TOGGLE

(WORKTOOLPRIORITY)................... 222

SWITCHGP-DISCONNECT–BATTERY......... 200

SWITCH GP-MAGNETIC (24-VOLT)

(AIRINLETHEATERRELAY)................ 201

SWITCH GP-MAGNETIC–

AIRINLETHEATERRELAY................. 201

SWITCHGP-MAGNETIC–STARTRELAY....... 202

SWITCH GP-POSITION–

HYDRAULICLOCKOUT..................... 203

SWITCH GP-REFUE LING–

FUELTANKSHUTOFF...................... 204

SEBP4861-02 INDEX A23
