CAT 315 Part Manual Page 634

Part Manual
HYDRAULIC SYSTEM
302-3258 LINES GP-PILOT (contd. ) i03146252
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
44 2 286-6663 1 HOSE AS
E2145-8495 GUARD (74-CM)
I45 3 286-6717 1 HOSE AS
46 1 302-3325 1 SUPPORT AS
47 3 307-4847 1 BRACKET
CI 48 2 307-5000 1 HOSE AS
I49 1 307-5238 1 HOSE AS
CI 50 3 307-5289 1 HOSE AS
51 2 309-5769 1 SWITCH AS-PRESSURE (PILOT, BOOM UP)
2 102-8802 1 KIT-RECEPTACLE (2-PIN)
(INCLUDES RECEPTACLE AS & WEDGE)
2 9X-3401 2 PIN-CONNECTOR (16-GA TO 18-GA)
–OR–
2 126-1767 2 PIN-CONNECTOR (14-GA)
52 1 317-4755 1 SUPPORT AS
C53 2 325-8984 1 SUPPORT AS
C54 3 325-9177 1 HOSE AS
C55 3 325-9213 1 HOSE AS
56 2 148-8318 1 CONNECTOR AS
2 3K-0360 1 SEAL-O-RING
2 6V-8397 1 SEAL-O-RING
2 6V-8634 1 CONNECTOR
57 2,3 148-8336 6 CONNECTOR AS
(EACH INCLUDES)
2,3 3J-1907 1 SEAL-O-RING
2,3 6V-8397 1 SEAL-O-RING
2,3 6V-8636 1 CONNECTOR
C58 1 148-8338 1 CONNECTOR AS
1 3J-1907 1 SEAL-O-RING
1 6V-8397 1 SEAL-O-RING
1 8T-0075 1 CONNECTOR
59 2 148-8353 2 ELBOW AS
(EACH INCLUDES)
2 3J-1907 1 SEAL-O-RING
2 6V-8397 1 SEAL-O-RING
2 6V-9001 1 ELBOW
60 1,2 148-8367 2 ELBOW AS
(EACH INCLUDES)
1,2 6V-8397 1 SEAL-O-RING
1,2 6V-9850 1 ELBOW
61 2 148-8372 1 ELBOW AS
2 2M-9780 1 SEAL-O-RING
2 6V-8398 1 SEAL-O-RING
2 6V-8721 1 ELBOW
62 2 148-8374 1 ELBOW AS
2 3K-0360 1 SEAL-O-RING
2 6V-8397 1 SEAL-O-RING
2 6V-8723 1 ELBOW
C 63 1,2,3 148-8378 12 ELBOW AS
(EACH INCLUDES)
1,2, 3 3J-1907 1 SEAL-O-RING
1,2, 3 6V-8397 1 SEAL-O-RING
1,2, 3 6V-8724 1 ELBOW
64 2 148-8407 2 PLUG AS
(EACH INCLUDES)
2 3J-1907 1 SEAL-O-RING
2 9S-4191 1 PLUG-O-RING
65 2,3 148-8433 2 TEE AS
(EACH INCLUDES)
604 HYDRAULIC SYSTEM 2of6 SEBP 4861-02
