CAT 315 Part Manual Page 621

Part Manual
HYDRAULIC SYSTEM
302-3195 LINES GP-PILOT (contd. ) i03148224
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
44 2 275-1444 2 GROMMET
I45 1 275-1624 1HOSEAS
46 1 278-6613 1 SUPPORT AS
I47 1 278-6623 1HOSEAS
48 3 281-5898 1TEEAS
3 3J-1907 1 SEAL-O-RING
3 6V-8398 2 SEAL-O-RING
3 153-6270 1TEE
Y49 3 285-1613 1 VALVE GP-PRESSURE REDUCING (BOOM PRIORITY) 718
50 1 286-6560 1HOSEAS
E17I-7439 GUARD (390-CM)
I51 1 292-7446 1HOSEAS
M52 3 099-3649 2 BOLT (M8X1.25X40-MM)
53 2 115-8645 1 GUARD
54 2,3,4 148-8336 10 CONNECTOR AS
(EACH INCLUDES)
2,3, 4 3J-1907 1 SEAL-O-RING
2,3, 4 6V-8397 1 SEAL-O-RING
2,3, 4 6V-8636 1 CONNECTOR
55 2 148-8340 2 CONNECTOR AS
(EACH INCLUDES)
2 3K-0360 1 SEAL-O-RING
2 6V-8398 1 SEAL-O-RING
2 6V-8639 1 CONNECTOR
56 3,4 148-8353 3 ELBOW AS
(EACH INCLUDES)
3,4 3J-1907 1 SEAL-O-RING
3,4 6V-8397 1 SEAL-O-RING
3,4 6V-9001 1 ELBOW
57 3 148-8367 1 ELBOW AS
3 6V-8397 1 SEAL-O-RING
3 6V-9850 1 ELBOW
58 2,3,4 148-8378 10 ELBOW AS
(EACH INCLUDES)
2,3, 4 3J-1907 1 SEAL-O-RING
2,3, 4 6V-8397 1 SEAL-O-RING
2,3, 4 6V-8724 1 ELBOW
59 2,3,4 148-8407 10 PLUG AS
(EACH INCLUDES)
2,3, 4 3J-1907 1 SEAL-O-RING
2,3, 4 9S-4191 1 PLUG-O-RING
60 2 148-8411 1PLUGAS
2 3K-0360 1 SEAL-O-RING
2 9S-4185 1 PLUG-O-RING
61 4 148-8433 2TEEAS
(EACH INCLUDES)
4 6V-8397 2 SEAL-O-RING
4 6V-9836 1 TEE-SWIVEL
62 3,4 148-8435 3TEEAS
(EACH INCLUDES)
3,4 3J-1907 1 SEAL-O-RING
3,4 6V-8397 2 SEAL-O-RING
3,4 6V-8781 1 TEE-FACE SEAL
63 3 148-8439 1TEEAS
3 3J-1907 1 SEAL-O-RING
3 6V-8397 2 SEAL-O-RING
3 6V-8774 1TEE
64 2 150-3036 1 ELBOW AS
2 3J-1907 1 SEAL-O-RING
SEBP4861-02 2of7 HYDRAULIC SYSTEM 591
