CAT 315 Part Manual Page 474

Part Manual
HYDRAULIC SYSTEM
259-0869 FILTE
R GP-O IL
–HYDRAULI C, MAIN RETURN
S/N: CJN1 -UP
PART OF 260-820
5 TANK & FILTER GP-HYDRAULI C
SMCS-3004, 4295, 431F, 5068, 5091, 5092 i02854827
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 283-6089 1 SEAL-O-RING
21 9S-5282 4 WASHER-HARD (8.8X14.5X2-MM THK)
M3 1 8T-4200 4 BOLT (M8X1.25X
16-MM)
41 2S-8439 1 SEAL-O-RING
51 266-7800 1 HOUSING GP-FILTER
M1095-0757 2 SCREW-MACHINE (
M6X1X8.6-MM)
1 274-2709 1 FLANGE AS
1 283-6090 1 SEAL-O-RING
61 266-7799 1 BLOCK AS
71 283-6090 1 SEAL-O-RING
81 266-7791 1 COVER
Y9 1 266-7792 1 FILTER GP-OIL (HY
DRAULIC, MAIN RETURN)
445
M10 1 8T-4184 4 BOLT (M12X1.75X45-MM)
11 1 8T-4223 4 WASHER-HARD (13.5X25.5X3-MM THK)
M-METRIC PART
Y-SEPARATE ILLUSTR
ATION
GRAPHIC #1 <END> g01305252
444 HYDRAULIC SYSTEM 1of1 SEBP 4861-02
