CAT 315 Part Manual Page 572

Part Manual
HYDRAULIC SYSTEM
260-8204 LINES
GP-HYDRAULIC
S/N: CJN1-945
PART OF 260-820
3 TANK & MTG GP-HYDRAULIC
SMCS-5057 i02877611
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 4I-9527 2 BAND-MARKER (GREEN, R3)
21 7K-1181 4 STRAP-CABLE
31 164-6874 1 FITTING AS-ELB
OW
1 3J-1907 1 SEAL-O-RING
1 085-7356 1 FITTING
Y4 1 221-5069 1 FITTING GP-HYDR
AULIC (TEE)
447
I5 1 269-9714 1 HOSE AS
61 269-9721 1 TUBE AS
71 317-4746 1 HOSE AS
I8 1 115-8631 1 HOSE AS
91 148-8340 2 CONNECTOR AS
(EACH INCLUDES)
1 3K-0360 1 SEAL-O-RING
1 6V-8398 1 SEAL-O-RING
1 6V-8639 1 CONNECTOR
10 1 148-8345 1 CONNECTOR AS
1 2M-9780 1 SEAL-O-RING
1 6V-8398 1 SEAL-O-RING
1 6V-8638 1 CONNECTOR
11 1 148-8347 1 ELBOW AS
1 3D-2824 1 SEAL-O-RING
1 6V-9007 1 ELBOW
1 6V-9746 1 SEAL-O-RING
12 1 148-8359 1 ELBOW AS
1 3K-0360 1 SEAL-O-RING
1 6V-9746 1 SEAL-O-RING
1 6V-9877 1 ELBOW
13 1 148-8372 1 ELBOW AS
1 2M-9780 1 SEAL-O-RING
1 6V-8398 1 SEAL-O-RING
1 6V-8721 1 ELBOW
14 1 148-8407 1 PLUG AS
1 3J-1907 1 SEAL-O-RING
1 9S-4191 1 PLUG-O-RING
15 1 150-4043 1 CONNECTOR AS
1 3J-1907 1 SEAL-O-RING
1 6V-8398 1 SEAL-O-RING
1 6V-9873 1 CONNECTOR
16 1 164-5608 1 CONNECTOR AS
1 3K-0360 1 SEAL-O-RING
1 6V-8398 1 SEAL-O-RING
1 8T-1687 1 CONNECTOR
17 1 4J-0527 1 SEAL-O-RING
18 1 6D-1641 1 CLIP
19 1 8T-4121 1 WASHER-HARD (11X21X2
.5-MM THK)
M20 1 8T-4137 1 BOLT (M10X1.5X20-MM)
21 1 8T-4223 4 WASHER-HARD (13.5X25.5X3-MM THK)
M22 1 8T-6868 4 BOLT (M12X1.75X80-MM)
I-REFER TO HYDRAULIC INFORMATION SYSTEM
M-METRIC PART
Y-SEPARATE ILLUSTRATION
542 HYDRAULIC SYSTEM 1of2 SEBP 4861-02
