CAT 315 Part Manual Page 627

Part Manual
HYDRAULIC SYSTEM
302-3258 LINES
GP-PILOT
–SYSTEM 20, WORK TOOL PRIORITY
S/N: CJN1 -UP
PART OF 259-755
7 CONTROL AR-AUXILIARY
AN ATTACHMENT
TYPE 1
SMCS-5057, 5059 i02866151
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
I1 3 4I-0836 1HOSEAS
I2 3 4I-1780 1HOSEAS
I3 3 4I-1783 1HOSEAS
41 4I-3941 1 FITTING AS
I5 3 4I-5906 1HOSEAS
63 4I-9521 2 BAND-MARKER (RED, L1)
73 4I-9522 4 BAND-MARKER (YELLOW, L2)
81 4I-9523 6 BAND-MARKER (BLUE, L3)
92,3 4I-9524 4 BAND-MARKER (BROWN, L4)
10 3 4I-9525 2 BAND-MARKER (ORANGE, R1)
11 1,2 4I-9527 6 BAND-MARKER (GREEN, R3)
I121,2 5I-4396 2HOSEAS
13 3 5P-5148 1 STRAP-TIE
14 1,2,3 7K-1181 13 STRAP-CABLE
I15 3 087-5303 1HOSEAS
I16 1 087-5762 1HOSEAS
I17 1 087-5766 1HOSEAS
I18 3 104-8771 1HOSEAS
I19 3 104-8838 1HOSEAS
20 3 104-8903 1 GUARD
I21 3 108-7393 1HOSEAS
I22 3 115-3667 1HOSEAS
Y23 2 121-6303 1 VALVE GP-SOLENOID (WORK TOOL PRIORITY) 737
Y24 2 123-2430 1 VALVE GP-SHUTTLE 729
25 2 150-4027 2TEEAS
(EACH INCLUDES)
2 3E-2310 1TEE
2 3J-1907 1 SEAL-O-RING
2 6V-8397 1 SEAL-O-RING
26 2,3 164-6874 4 FITTING AS-ELBOW
(EACH INCLUDES)
2,3 3J-1907 1 SEAL-O-RING
2,3 085-7356 1 FITTING
C27 1 309-5769 1 SWITCH AS-PRESSURE (PILOT, BOOM UP)
1 102-8802 1 KIT-RECEPTACLE (2-PIN)
(INCLUDES RECEPTACLE AS & WEDGE)
1 9X-3401 2 PIN-CONNECTOR (16-GA TO 18-GA)
–OR–
1 126-1767 2 PIN-CONNECTOR (14-GA)
Y28 2 171-0188 1 VALVE GP-SOLENOID
(NEG FLOW CONT, PROPN RED VALVE)
738
C29 2 317-4755 1 SUPPORT AS
I30 3 199-2013 1HOSEAS
E37I-7439 GUARD (98-CM)
Y31 3 226-3109 1 VALVE GP-SOLENOID (NEGATIVE FLOW CONTROL) 739
32 1 260-8071 1HOSEAS
I33 1 266-1293 2HOSEAS
I34 1 266-1389 1HOSEAS
35 2 269-9717 1 PLATE
I36 1 269-9754 1HOSEAS
Y37 2 270-5766 1 VALVE GP-SOLENOID & PRESS REDC
(WORK TOOL CONTROL)
748
I38 1 272-4180 1HOSEAS
39 1 272-4186 1HOSEAS
SEBP4861-02 1of6 HYDRAULIC SYSTEM 597
