CAT 315 Part Manual Page 816

Part Manual

Page of 1181

/ 1181

WORK TOOLS

106-6757 ADJUS

TER GP -BUC KET

S/N: CJN1 -UP

PART OF 239-250

9, 239-2510, 239-2511, 239-2512, 239-2513, 239-2514, 239-2515,

239-2516, 239-

2517, 239-2518, 305-1667, 305-1671 BUCKET & ADJUSTER GP

AN ATTACHMENT

SMCS-6513, 6700 i02210037

NOTE

REF

GRAPHIC

REF PART NUM BER QTY

PART NAM E

123456(PRODUCT LEVE

SEE

PAGE

B1 1 107-9965 6 SHIM (1-MM THK)

B2 1 107-9966 4 SHIM (0.5-MM THK)

31 193-5014 1 PIN

41 107-9967 1 PLATE

M5 1 8T-4193 4 BOLT (M16X2X50-MM)

61 9X-8257 4 WASHER (17.5X30

X3.5-MM THK)

71 193-5013 1 FLANGE

B-USE AS REQUIRED

M-METRIC PART

GRAPHIC #1 <END> g00767965

786 WORK TOOLS 1of1 SEBP 4861-02
