CAT 315 Part Manual Page 594

Part Manual
HYDRAULIC SYSTEM
260-8225 LINES
GP-PILOT
–SYSTEM 23, COMBINED FUNCTION
S/N: CJN1 -UP
PART OF 270-575
1 CONTROL AR-AUXILIARY
AN ATTACHMENT
TYPE 2
SMCS-5057, 5059 i03063022
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
CI 1 1 4I-1037 1 HOSE AS
21 4I-3941 1 FITTING AS
1 6V-8553 1 NUT (11/16-16-THD)
CI 3 1 4I-5906 1 HOSE AS
41 4I-9521 2 BAND-MARKER (RED, L1)
51 4I-9522 2 BAND-MARKER (YELLOW, L2)
61 4I-9523 4 BAND-MARKER (BLUE, L3)
71 4I-9524 4 BAND-MARKER (BROWN, L4)
81 4I-9527 4 BAND-MARKER (GREEN, R3)
91 6V-0852 4 CAP-DUST
10 1 7K-1181 11 STRAP-CABLE
I11 1 087-5762 1 HOSE AS
Y12 1 121-6303 1 VALVE GP-SOLENOID
(SYSTEM 24, COMBINED FUNCTION)
737
Y13 1 123-2430 1 VALVE GP-SHUTTLE 729
14 1 148-8433 2 TEE AS
(EACH INCLUDES)
1 6V-8397 2 SEAL-O-RING
1 6V-9836 1 TEE-SWIVEL
15 1 164-6874 2 FITTING AS-ELBOW
(EACH INCLUDES)
1 3J-1907 1 SEAL-O-RING
1 085-7356 1 FITTING
CI 16 1 164-8988 1 HOSE AS
Y17 1 171-0188 1 VALVE GP-SOLENOID
(NEG FLOW CONT, PROPN RED VALVE)
738
C18 1 212-5402 1 HOSE AS
Y19 1 259-7430 1 VALVE GP-SOLENOID (PRESSURE REDUCING) 741
CI 20 1 269-9700 1 HOSE AS
21 1 269-9717 1 PLATE
I22 1 272-4180 1 HOSE AS
I23 1 272-4183 1 HOSE AS
24 1 275-1442 1 CLIP (TAB)
25 1 275-1443 1 CLIP (SLOT)
26 1 275-1444 1 GROMMET
I27 1 275-1487 1 HOSE AS
28 1 278-6905 1 HOSE AS
29 1 282-7106 1 GROMMET
30 1 282-7198 1 HOSE AS
I31 1 302-3188 1 HOSE AS
CI 32 1 307-5000 1 HOSE AS
33 1 309-5769 1 SWITCH AS-PRESSURE (PILOT, BOOM UP)
1 102-8802 1 KIT-RECEPTACLE (2-PIN)
(INCLUDES RECEPTACLE AS & WEDGE)
1 9X-3401 2 PIN-CONNECTOR (16-GA TO 18-GA)
–OR–
1 126-1767 2 PIN-CONNECTOR (14-GA)
34 1 317-4755 1 SUPPORT AS
C35 1 325-9013 1 SUPPORT AS
C36 1 325-9177 1 HOSE AS
37 1 148-8336 4 CONNECTOR AS
(EACH INCLUDES)
1 3J-1907 1 SEAL-O-RING
1 6V-8397 1 SEAL-O-RING
564 HYDRAULIC SYSTEM 1of3 SEBP 4861-02
