CAT 315 Part Manual Page 663

Part Manual
HYDRAULIC SYSTEM
260-8212 LINES
GP-TRAVEL MOTOR
–LONG CARRIAGE
S/N: CJN485-UP
PART OF 259-754
7 HYDRAULIC AR
SMCS-5057, 5058 i03248906
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 108-7304 2 GROMMET
21 124-0986 2 GROMMET
Y3 1 162-4696 1 SWIVEL GP 664
41 187-5915 2HOSEAS
CI 5 1 7I-8249 2HOSEAS
I6 1 196-0800 4HOSEAS
71 148-8325 2 CONNECTOR AS
(EACH INCLUDES)
1 3J-1907 1 SEAL-O-RING
1 4J-5477 1 SEAL-O-RING
1 6V-8641 1 CONNECTOR
81 148-8327 4 CONNECTOR AS
(EACH INCLUDES)
1 3D-2824 1 SEAL-O-RING
1 6V-8637 1 CONNECTOR
1 6V-9746 1 SEAL-O-RING
C9 1 148-8364 2 ELBOW AS
(EACH INCLUDES)
1 3K-0360 1 SEAL-O-RING
1 6V-8398 1 SEAL-O-RING
1 6V-8625 1 ELBOW
10 1 148-8368 2 ELBOW AS
(EACH INCLUDES)
1 3J-1907 1 SEAL-O-RING
1 4J-5477 1 SEAL-O-RING
1 6V-8627 1 ELBOW
11 1 148-8436 1TEEAS
1 3K-0360 1 SEAL-O-RING
1 6V-8398 2 SEAL-O-RING
1 6V-8775 1 TEE-FACE SEAL
12 1 1P-3703 4 SEAL-RECTANGULAR
13 1 6V-0400 8 FLANGE-HALF
14 1 7K-1181 4 STRAP-CABLE
15 1 8T-4121 4 WASHER-HARD (11X21X2.5-MM THK)
M16 1 8T-4137 4 BOLT (M10X1.5X20-MM)
M17 1 8T-4184 16 BOLT (M12X1.75X45-MM)
18 1 8T-4223 16 WASHER-HARD (13.5X25.5X3-MM THK)
B19 1 1U-8846 SEALANT-GASKET
B-USE AS REQUIRED
C-CHANGE FROM PREVIOUS TY
PE
I-REFER TO HYDRAULIC INFO
RMATION SYSTEM
M-METRIC PART
Y-SEPARATE ILLUSTRATION
SEBP4861-02 1of2 HYDRAULIC SYSTEM 633
