CAT 315 Part Manual Page 818

Part Manual
WORK TOOLS
239-2509 BUCKE
T & A DJUSTER GP
–GENERA L PURPOSE
S/N: CJN1 -UP
617-MM (24-IN)
WIDE X 0.35-CU M (0.45-CU YD) CAPACITY. K-80 ADAPTERS, (3X)
AN ATTACHMENT
TYPE 2
SMCS-6503, 6513 i02895018
NOTE PART NUMBER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
Y 106-6757 1 ADJUSTER GP-BUCKET 786
CY 305-1689 1 BUCKET AS-GENERAL PURPOSE 797
C-CHANGE FROM PRE
VIOUS TYPE
Y-SEPARATE ILLUS
TRATION
<END>
239-2510 BUCKET & A DJUSTER GP–EXCAVATION
S/N: CJN1 -UP
770-MM (30-IN) WIDE X 0.5-CU M (0.6-CU YD) CAPACITY. K-80 ADAPTERS, (4X)
AN ATTACHMENT
SMCS-6503, 6513 i02895026
NOTE PART NUMBER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
Y 106-6757 1 ADJUSTER GP-BUCKET 786
Y 239-2520 1 BUCKET AS-EXCAVATION (GENERAL PURPOSE) 794
–OR–
Y 305-1690 1 BUCKET AS-GENERAL PURPOSE 798
Y-SEPARATE ILLUSTRATION
<END>
239-2511 BUCKET & A DJUSTER GP–EXCAVATION
S/N: CJN1 -UP
922-MM (36-IN) WIDE X 0.6-CU M (0.8-CU YD) CAPACITY. K-80 ADAPTERS, (5X)
AN ATTACHMENT
SMCS-6503, 6513 i02895032
NOTE PART NUMBER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
Y 106-6757 1 ADJUSTER GP-BUCKET 786
Y 239-2521 1 BUCKET AS-EXCAVATION (GENERAL PURPOSE) 795
–OR–
Y 305-1691 1 BUCKET AS-GENERAL PURPOSE 799
Y-SEPARATE ILLUSTRATION
<END>
788 WORK TOOLS SEBP4861-02
