CAT 315 Part Manual Page 267

Part Manual
ELECTRICAL AND STARTING SYSTEM
251-0435 WIRIN
G GP -CON SOLE
–RH
S/N: CJN1 -UP
PART OF 251-043
3 WIRING GP-CONSOLE
SMCS-1408 i02553916
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 3S-2093 3 STRAP-CABLE
21 7K-1181 1 STRAP-CABLE
31 283-3074 1 SWITCH AS-TOGG
LE
(AUTO/MANUAL E
NG SPEED CONTROL)
41 163-6711 1 SWITCH AS-TOGGLE (MANUAL ENGINE SPEED CONTROL)
51 163-6795 3 STRAP-CABLE
61 251-0602 1 BRACKET
71 259-4877 1 HARNESS AS-CONSOLE (RH)
1 102-8806 1 KIT-RECEPTACLE (8-PIN)
(INCLUDES RECEPT
ACLEAS&WEDGE)
1 3S-2093 10 STRAP-CABLE
1 7Y-3967 2 TERMINAL AS
1 7Y-3963 1 TERMINAL (RECEPT
ACLE)
1 7Y-3965 1 TUBE (RECEPTACLE TERMINAL)
1 102-7964 1 CONNECTOR-PLUG
1 102-7965 14 TERMINAL (FEMALE)
E1125-7874 TUBE-HEAT SHRINK (5.72-MM DIA) (10-CM)
E1125-7875 TUBE-HEAT SHRINK (7.44-MM DIA) (10-CM)
1 155-2265 1 KIT-CONNECTING PL
UG (8-PIN)
(INCLUDES PLUG AS, WEDGE & INTERFACE SEAL)
1 9X-3401 2 PIN-CONNECTOR (16-GA TO 18-GA)
–OR–
1 126-1767 2 PIN-CONNECTOR (14-GA)
1 230-4009 1 PLUG AS-CONNECTOR (12-PIN)
1 230-4011 1 PLUG AS-CONNECTOR (2
-PIN)
1 230-5008 1 PLUG AS-CONNECTOR (4-PIN)
1 230-5010 1 PLUG AS-CONNECTOR (6-PIN)
1 231-2295 1 PLUG AS-CONNECTOR (8
-PIN)
1 239-7352 1 PLUG AS-CONNECTOR (6-PIN)
1 243-4505 1 RECEPTACLE AS-CONNECTOR (2-PIN)
1 243-4510 1 RECEPTACLE AS-CONNE
CTOR (12-PIN)
1 247-2693 1 RECEPTACLE AS-CONNECTOR (6-PIN)
M8 1 9X-2042 3 SCREW-TRUSS HEAD (M6X1X12-MM)
E-ORDER BY THE CENTIMETE
R
M-METRIC PART
SEBP4861-02 1of2 ELECTRICAL AND STARTING SYSTEM 237
