CAT 315 Part Manual Page 60

Part Manual
BASIC ENGINE
255-3035 MOUNT
ING GP -ENG INE
S/N: CJN1 -UP
PART OF 279-774
8 INSTALLATION AR-ENGINE
SMCS-1152 i02600442
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 099-4707 4 WASHER (16.5X90X9-MM THK)
21 118-9941 4 SUPPORT AS
31 266-6203 1 BRACKET-FRONT
(RH)
41 266-6204 1 BRACKET-FRONT (LH)
51 266-6205 1 BRACKET-REAR (RH)
61 266-6206 1 BRACKET-REAR (L
H)
71 266-6258 2 MOUNT-RUBBER
81 266-6259 2 MOUNT-RUBBER
91 266-6303 2 MOUNT-RUBBER
10 1 266-6304 2 MOUNT-RUBBER
M11 1 8T-4174 4 BOLT (M16X2X120-MM)
12 1 8T-4223 16 WASHER-HARD (13.
5X25.5X3-MM THK)
M13 1 8T-4956 16 BOLT (M12X1.75X35-MM)
14 1 9X-8257 8 WASHER (17.5X30X3.5-MM THK)
M-METRIC PART
30 BASIC ENGINE 1of2 SEBP 4861-02
