CAT 315 Part Manual Page 57

Part Manual
BASIC ENGINE
296-4788 HOUSI
NG GP -FRO NT
S/N: JKH1 -UP
PART OF 272-481
7 ENGINE AR
ALSO AN ATTACHME
NT
SMCS-1151, 1162, 1206 i02830615
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 222-8292 1 POINTER
21 294-1731 1 BOLT (M8X1.25X19.5-MM)
31 6V-8236 1 PIN-SPRING
41 294-1732 1 PLATE
M5 1 6V-5215 2 BOLT (M8X1.25X16-MM)
61 297-7646 2 BOLT (M8X1.25X9
5.5-MM)
71 178-6538 1 COVER AS
M8 1 8T-4137 6 BOLT (M10X1.5X20-MM)
M9 1 5I-7610 1 BOLT (M10X1.5X20
-MM)
10 1 297-7647 6 BOLT (M10X1.5X77-MM)
M11 1 8T-4172 2 BOLT (M10X1.5X80-MM)
12 1 5I-7896 4 BOLT (M8X1.25X95
-MM)
13 1 7X-0796 6 LOCKWASHER
14 1 294-1733 1 GASKET
15 1 294-1734 1 GASKET
16 1 212-8571 1 COVER
17 1 212-8572 1 GASKET
18 1 196-8366 1BOLT
19 1 294-1735 5 BOLT (M8X1.25X90.5-MM)
M20 1 294-7251 6 BOLT AS (M8X20X1-MM)
M21 1 294-1726 3 BOLT (M10X1.5X37-
MM)
22 1 096-9435 1PLUG
23 1 096-9532 1 WASHER (15.8X22.5X2-MM THK)
24 1 096-9528 1 SEAL-O-RING
25 1 6F-7556 2 COVER
26 1 5I-7632 1PIPE
27 1 296-4700 1BODYAS
27A 1 294-1728 1 GEAR
27B 1 125-2950 1 GEAR AS (9-TEETH)
27C 1 195-8225 1 CAP (MAIN BEARING)
30 1 294-1729 1GEARAS
31 1 5I-7656 1SEAL
32 1 6F-7557 2 GASKET
33 1 5I-7683 1 SPINDLE
34 1 178-6537 1 GASKET
35 1 5I-7558 1 GEAR AS (9-TEETH)
36 1 096-1024 1BOLTAS
37 1 195-8212 1PLUG
M-METRIC PART
SEBP4861-02 1of2 BASIC ENGINE 27
