CAT 315 Part Manual Page 446

Part Manual
HYDRAULIC SYSTEM
281-8979 CYLIN
DER GP -BUC KET
S/N: CJN1 -UP
100-MM (3.9-IN
) BORE X 1048-MM (41.2-IN) STROKE
PART OF 302-1730
CYLINDER & SEAL GP-BUCKET
AN ATTACHMENT
SMCS-5457 i02842163
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 3E-3377 1 WEDGE-RECEPTACLE LOCK (4-PIN)
J2 1 9X-7298 1 SEAL AS
31 099-5400 1 RING-RETAININ
G
41 102-2244 1 GROMMET
51 133-6677 1 HEAD
J6 1 133-6716 1 RING-BACKUP
J7 1 170-9857 1 SEAL-U-CUP
81 212-0907 1 PLATE-CONNECTOR
91 217-3312 1 MAGNET
10 1 217-8763 1 COVER-PROTECTION
11 1 246-9113 1 RETAINER
12 1 281-8980 1 CYLINDER AS
12A 1 260-2528 1 BEARING-SLEEVE
13 1 281-8984 1 ROD AS
13A 1 240-2912 1 BEARING-SLEEVE
14 1 281-8986 1 PISTON
15 1 281-8989 1 SENSOR GP-POSITION (BUCKET)
1 9X-3401 3 PIN-CONNECTOR (16
-GA TO 18-GA)
J16 1 093-1519 1 RING-BACKUP
M17 1 095-1267 2 SETSCREW-SOCKET (M110X1.5-THD)
J18 1 095-1714 1 SEAL-O-RING
19 1 114-0753 1 BEARING-SLEEVE
J20 1 143-8024 1 RING
J21 1 143-8025 1 RING
J22 1 143-8033 1 RING
J23 1 165-9283 1 SEAL-LIP TYPE
J24 1 170-9841 1 SEAL-BUFFER
25 1 188-2199 1 SEAL-O-RING
26 1 215-1942 1 RING-BACKUP
27 1 102-8804 1 KIT-RECEPTACLE (4-
PIN)
(INCLUDES RECEPTACLE AS & WEDGE)
28 1 3V-2431 2 WASHER (10.2X16X2-MM THK)
M29 1 6V-8223 1 SETSCREW-SOCKET (M1
0X1.5X16-MM)
M30 1 7Y-5216 8 BOLT-SOCKET HEAD (M20X2.5X80-MM)
31 1 8T-8737 1 PLUG-SEAL
M32 1 8T-8894 2 BOLT-SOCKET HEAD (M10
X1.5X20-MM)
E33 1 9X-1386 SLEEVE (10-CM EACH)
AVAILABLE REPAIR KIT(S):
J 179-9638 1 KIT-SEAL (BUCKET CYLINDER)
E-ORDER BY THE CENTIMETER
J-KIT MARKED J SERVICES PA
RT(S) MARKED J
M-METRIC PART
416 HYDRAULIC SYSTEM 1of2 SEBP 4861-02
