CAT 315 Part Manual Page 260

Part Manual
ELECTRICAL AND STARTING SYSTEM
275-6880 WIRIN
G GP-C OMMU NICATION
–PRODUCT LINK 321SR
S/N: CJN1 -UP
PART OF 260-707
2, 301-2590 INSTALLATION AR-COMMUNICATION
AN ATTACHMENT
SMCS-1408 i02753051
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 4I-7889 1 SPACER (11X25X45-MM THK)
21 7K-1181 5 STRAP-CABLE
31 9X-3495 1 CLIP AS
1 8C-3334 2 RIVET-TUBULAR
41 116-0118 3 CLIP
51 259-4887 1 HARNESS AS-CONT
ROL (PRODUCT LINK)
1 3S-2093 2 STRAP-CABLE
E1125-7874 TUBE-HEAT SHRINK (5.72-MM DIA) (15-CM)
E1125-7875 TUBE-HEAT SHRINK
(7.44-MM DIA) (5-CM)
1 126-1774 1 COVER-CONNECTOR
1 160-7690 1 PLUG AS-CONNECTOR (70-PIN)
1 159-9322 1 SEAL-O-RING
1 230-5010 2 PLUG AS-CONNECTOR (6-PIN)
1 243-4508 2 RECEPTACLE AS-CONNECTOR (6-PIN)
61 259-4940 1 HARNESS AS-WIRIN
G (SERVICE CONNECTOR)
1 243-4508 1 RECEPTACLE AS-CONNECTOR (6-PIN)
71 275-7047 1 HARNESS AS-CONTROL (SERVICE CONNECTOR)
1 155-2255 1 KIT-CONNECTING PL
UG (12-PIN)
(INCLUDES PLUG AS, WEDGE & INTERFACE SEAL)
1 230-5010 1 PLUG AS-CONNECTOR (6-PIN)
1 243-4508 1 RECEPTACLE AS-CONN
ECTOR (6-PIN)
81 091-9035 1 SPACER (11X25X20-MM THK)
91 111-4837 1 CLIP
10 1 132-5789 1 CLIP
11 1 8T-4121 2 WASHER-HARD (11X21X2.5-MM THK)
M12 1 8T-4136 1 BOLT (M10X1.5X25-MM)
M13 1 8T-4185 1 BOLT (M10X1.5X50-MM
)
M14 1 8T-4191 1 BOLT (M10X1.5X16-MM)
M15 1 8T-5005 1 BOLT (M10X1.5X70-MM)
E-ORDER BY THE CENTIMET
ER
M-METRIC PART
230 ELECTRIC AL AND S TARTING SY STEM 1of2 SEBP 4861-02
