CAT 315 Part Manual Page 240

Part Manual
ELECTRICAL AND STARTING SYSTEM
259-5166 WIRIN
G GP- AUX START RECEPTACLE
–JUMP START
S/N: CJN1 -UP
AN ATTACHMENT
SMCS-1408, 1463 i02752944
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 8N-0869 1 COVER-TERMINAL (RED)
21 8S-2634 1 COVER AS
31 9S-9015 1 RECEPTACLE AS
1 1S-7251 2 TERMINAL-CABLE (00-GA, 1/2-IN BOLT)
E15P-0747 CABLE (00-GA, BLACK) (41-CM)
E15P-0761 CABLE (00-GA, RE
D) (38-CM)
D 6V-2722 1 TUBE-HEAT SHRINK (25.4-MM DIA) (1-M)
41 204-1673 1 STRAP-CABLE
51 267-7583 1 CABLE AS
1 1S-7251 1 TERMINAL-CABLE (00-GA, 1/2-IN BOLT)
E15P-0761 CABLE (00-GA, RED) (69-CM)
1 8N-0869 1 COVER-TERMINAL (
RED)
1 8N-1725 1 COVER-TERMINAL (RED)
1 3S-6049 1 TERMINAL AS-BATTERY (POSITIVE)
1 1M-6119 1 BOLT (5/16-18X1.3
75-IN)
1 1M-6120 1 NUT (5/16-18-THD)
61 267-7584 1 CABLE AS
1 1S-7251 1 TERMINAL-CABLE (
00-GA, 1/2-IN BOLT)
1 1S-7252 1 TERMINAL-CABLE (00-GA, 3/8-IN BOLT)
E15P-0761 CABLE (00-GA, RED) (259-CM)
E16V-2722 TUBE-HEAT SHRINK (
25.4-MM DIA) (1-M)
1 8N-0869 1 COVER-TERMINAL (RED)
71 267-7585 1 BRACKET
81 267-7586 1 BRACKET AS
Y9 1 124-5814 1 BLOCK GP-JUNCTION 140
10 1 5P-4115 4 WASHER-HARD (7.2X19X2-MM THK)
11 1 8T-4121 6 WASHER-HARD (11X21
X2.5-MM THK)
M12 1 8T-4136 6 BOLT (M10X1.5X25-MM)
M13 1 8T-4970 4 BOLT (M6X1X14-MM)
D-ORDER BY THE METER
E-ORDER BY THE CENTIME
TER
M-METRIC PART
Y-SEPARATE ILLUSTRAT
ION
210 ELECTRIC AL AND S TARTING SY STEM 1of2 SEBP 4861-02
