CAT 315 Part Manual Page 736

Part Manual
HYDRAULIC SYSTEM
206-3305 VALVE
GP-PILOT
–JOYSTICK
S/N: CJN1 -UP
PART OF 259-776
2, 259-7763, 259-7764, 259-7765 CONTROL GP-JOYSTICK
FIELD REPLACEME
NT ORDER 297-0589–PAGE 713
AN ATTACHMENT
SMCS-5059 i02174618
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 165-9431 1 PLATE
21 4I-6365 1 JOINT
31 118-4087 4 SPRING
41 165-9444 2 SEAT-SPRING
(USED WITH REF NO 7 OR 7A SPRINGS)
–OR–
J1244-8496 2 SEAT-SPRING
(USED WITH REF NO 7B SPRINGS)
–OR–
L1244-8500 2 SEAT-SPRING
(USED WITH REF NO 7C SPRINGS)
51 096-1628 4 PLUG
61 165-9436 2 SEAT
71 165-9460 2 SPRING (STANDARD)
–OR–
7A 1 225-4815 2 SPRING (OPTIONAL)
(REDUCES OPERATING FORCE FOR IMPROVED INCHING
CONTROL)
–OR–
J7B 1 244-8494 2 SPRING (OPTIONAL)
(PROVIDES CONTROLLABILITY EQUAL TO A-SERIES
MACHINES)
–OR–
L7C 1 244-8498 2 SPRING (OPTIONAL)
(PROVIDES CONTROLLABILITY COMPARABLE TO A AND
B-SERIES MACHINES)
81 165-9461 4 SPRING (STANDARD)
–OR–
1 190-7750 4 SPRING (OPTIONAL)
(REDUCES OPERATING FORC
EBY30%)
–OR–
1 190-7751 4 SPRING (OPTIONAL)
(REDUCES OPERATING FORCE
BY 20%)
91 165-9439 1 BUSHING
10 1 165-9448 1 SEAL-O-RING
11 1 168-0794 1 PLATE
12 1 096-4498 2 WASHER
M13 1 6V-8337 2 BOLT-SOCKET HEAD (M8X1.25X35-MM)
14 1 171-0087 1 BELLOWS
M15 1 131-5915 1 NUT-SPECIAL
16 1 7Y-0468 1 PIN-SPRING
17 1 094-0876 4 SEAL
B18 1 099-6137 4 WASHER (6.1X9X0.2-MM THK)
19 1 165-9442 2 SPRING (STANDARD)
–OR–
19A 1 225-4816 2 SPRING (OPTIONAL)
(REDUCES OPERATING FORCE FOR IMPROVED INCHING
CONTROL)
–OR–
J19B 1 244-8495 2 SPRING (OPTIONAL)
(PROVIDES CONTROLLABILITY EQUAL TO A-SERIES
MACHINES)
–OR–
706 HYDRAULIC SYSTEM 1of3 SEBP 4861-02
