CAT 315 Part Manual Page 641

Part Manual
HYDRAULIC SYSTEM
260-8210 LINES
GP-PUMP
–OUTPUT, HYD OIL CLR BYPASS
S/N: CJN1 -UP
PART OF 259-754
7 HYDRAULIC AR
SMCS-5057 i02599675
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 8T-6703 2 CLAMP-HOSE
Y2 1 171-0002 1 VALVE GP-CHECK (COOLER BYPASS) 679
31 229-1023 1HOSE
I4 1 269-9901 1HOSEAS
I5 1 269-9904 1HOSEAS
I6 1 269-9907 1HOSEAS
I7 1 269-9911 1HOSEAS
81 269-9915 1 SUPPORT
91 269-9916 1TUBEAS
M10 1 101-7404 4 BOLT-SOCKET HEAD (M10X1.5X30-MM)
11 1 148-8335 2 CONNECTOR AS
(EACH INCLUDES)
1 5K-9090 1 SEAL-O-RING
1 6V-8635 1 CONNECTOR
1 7M-8485 1 SEAL-O-RING
12 1 164-4180 2PLUGAS
(EACH INCLUDES)
1 7M-8485 1 SEAL-O-RING
1 9S-4181 1 PLUG-O-RING
13 1 1P-4578 8 FLANGE-HALF
14 1 4J-0522 4 SEAL-O-RING
15 1 4J-0527 2 SEAL-O-RING
16 1 7G-5984 1 CLIP (TAB)
17 1 7G-5985 1 CLIP (SLOT)
18 1 8T-3440 1 GROMMET
19 1 8T-4121 16 WASHER-HARD (11X21X2.5-MM THK)
M20 1 8T-4139 4 BOLT (M12X1.75X30-M
M)
M21 1 8T-4183 4 BOLT (M12X1.75X40-MM)
M22 1 8T-4196 16 BOLT (M10X1.5X35-MM)
23 1 8T-4223 8 WASHER-HARD (13.5X25
.5X3-MM THK)
I-REFER TO HYDRAULIC INFORMATION SYSTEM
M-METRIC PART
Y-SEPARATE ILLUSTRATION
SEBP4861-02 1of2 HYDR AULIC SYSTEM 611
