CAT 315 Part Manual Page 649

Part Manual
HYDRAULIC SYSTEM
282-7080 LINES
GP-PUMP
S/N: CJN1 -UP
PART OF 270-595
4 CONTROL AR-AUXILIARY
AN ATTACHMENT
SMCS-5057 i02854826
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 7K-1181 7 STRAP-CABLE
21 134-6838 1 GUARD
I3 1 193-9994 1HOSEAS
41 199-2046 1 GUARD
51 317-4747 1 SUPPORT AS
61 272-4215 1 GROMMET
I7 1 272-4265 1HOSEAS
I8 1 278-6466 1HOSEAS
91 278-6592 1TEEAS
1 3D-2824 1 SEAL-O-RING
1 7J-9108 1 SEAL-O-RING
1 278-6493 1 TEE-ORPTOORFS
10 1 148-8315 1 CONNECTOR AS
1 2M-9780 1 SEAL-O-RING
1 6V-8642 1 CONNECTOR
1 7J-9108 1 SEAL-O-RING
11 1 148-8322 1 CONNECTOR AS
1 2M-9780 1 SEAL-O-RING
1 6V-8640 1 CONNECTOR
1 6V-9746 1 SEAL-O-RING
12 1 148-8335 1 CONNECTOR AS
1 5K-9090 1 SEAL-O-RING
1 6V-8635 1 CONNECTOR
1 7M-8485 1 SEAL-O-RING
13 1 148-8357 1 ELBOW AS
1 5K-9090 1 SEAL-O-RING
1 6V-9008 1 ELBOW
1 7M-8485 1 SEAL-O-RING
14 1 148-8360 1 ELBOW AS
1 6V-9182 1 ELBOW
1 6V-9746 1 SEAL-O-RING
1 7M-8485 1 SEAL-O-RING
15 1 164-5567 1 COUPLER AS-QUICK DIS
CONNECT
1 3J-1907 1 SEAL-O-RING
1 6V-3965 1 FITTING (QUICK DISCONNECT)
16 1 5P-7466 1 CLIP (SLOT)
17 1 5P-7467 1 CLIP (TAB)
18 1 5P-8112 1 GROMMET
19 1 6V-0852 1 CAP-DUST
20 1 8T-4121 2 WASHER-HARD (11X21X2.5-MM THK)
M21 1 8T-4137 2 BOLT (M10X1.5X20-MM)
22 1 8T-4223 1 WASHER-HARD (13.5X25.
5X3-MM THK)
M23 1 8T-4956 1 BOLT (M12X1.75X35-MM)
I-REFER TO HYDRAULIC INFORMATION SYSTEM
M-METRIC PART
SEBP4861-02 1of2 HYDRAULIC SYSTEM 619
