CAT 315 Part Manual Page 65

Part Manual
BASIC ENGINE
296-4796 PISTO
N & ROD GP
S/N: JKH1 -UP
PART OF 272-481
7 ENGINE AR
ALSO AN ATTACHME
NT
SMCS-1225 i02710557
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 310-9489 4 PISTON (STANDARD)
AB 310-9490 PISTON (0.25-MM OS)
AB 310-9491 PISTON (0.5-MM
OS)
21 094-7134 4PIN
31 5I-7667 8RING
J4 1 178-6543 4 SET-PISTON RING
(STANDARD)
ABJ 178-6544 SET-PISTON RING (0.25-MM OS)
ABJ 178-6545 SET-PISTON RING (0.5-MM OS)
51 294-1747 4RODAS
(EACH INCLUDES)
5A 1 094-7154 2 BOLT (M12X1.25-1X85-MM)
5B 1 094-7516 2 NUT (M12X1.25-THD
)
5C 1 296-4663 1 BUSHING
61 294-1748 8 BEARING
AB 1 297-7648 BEARING (0.25-MM
US)
AB 1 297-7649 BEARING (0.50-MM US)
AB 1 297-7650 BEARING (0.75-MM US)
A-NOT PART OF THIS GRO
UP
B-USE AS REQUIRED
J-INCLUDES COMPLETE
SET OF RINGS FOR ONE PISTON
GRAPHIC #1 <END> g01403170
