CAT 315 Part Manual Page 851

Part Manual
WORK TOOLS
268-7258 COUPLER AR-QUICK–WITH COUPLER PIN
S/N: CJN1 -UP
CANNOT BE USED WITH SHORT STICK
AN ATTACHMENT
SMCS-1408, 5057
, 6129
i02889023
NOTE PART NUMBER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
Y 259-0844 1 CYLINDER & LINES GP-BUCKET 396
Y 277-1212 1 LINES GP-COUPL
ER
487
Y 277-1213 1 LINKAGE GP-BUCKET 767
Y 253-6407 1 PIN GP-COUPLER 824
Y-SEPARATE ILLUST
RATION
<END>
268-7259 COUPLER AR-QUICK–WITHOUT COUPLER PI N
S/N: CJN1 -UP
AN ATTACHMENT
SMCS-1408, 5057, 6129 i03196445
NOTE PART NUMBER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
Y 259-0844 1 CYLINDER & LINES GP-BUCKET 396
Y 277-1212 1 LINES GP-COUPLER 487
Y 277-1213 1 LINKAGE GP-BUCKET (COUPLER) 767
Y-SEPARATE ILLUSTRATION
<END>
306-1336 COUPLER AR–WI TH COUPLER PIN
S/N: CJN1 -UP
AN ATTACHMENT
SMCS-1408, 5057, 6129 i02841181
NOTE PART NUMBER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
Y 259-0914 1 CYLINDER & LINES GP-BUCKET 396
Y 277-1212 1 LINES GP-COUPLER 487
Y 277-1213 1 LINKAGE GP-BUCKET 767
Y 253-6407 1 PIN GP-COUPLER 824
Y-SEPARATE ILLUSTRATION
<END>
306-1337 COUPLER A R–WITHOUT COUPLER PIN
S/N: CJN1 -UP
AN ATTACHMENT
SMCS-1408, 5057, 6129 i02841185
NOTE PART NUMBER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
Y 259-0914 1 CYLINDER & LINES GP-BUCKET 396
Y 277-1212 1 LINES GP-COUPLER 487
Y 277-1213 1 LINKAGE GP-BUCKET 767
Y-SEPARATE ILLUSTRATION
<END>
SEBP4861-02 WORK TOOLS 821
