CAT 315 Part Manual Page 425

Part Manual
HYDRAULIC SYSTEM
259-0837 CYLIN
DER & LINES GP-BOO M
–LH
S/N: CJN1 -UP
PART OF 330-877
7 BOOM AR, 260-6979, 301-2575 BOOM AR -1 PIECE LONG, 301-2479,
301-2517 SPECI
AL AR
AN ATTACHMENT
SMCS-5456, 7562 i03195680
NOTE PART NUMBER QTY
PART NAM E
123456(PRODUCT LEVE
L)
SEE
PAGE
Y 259-0839 1 CYLINDER & SEAL GP-BOOM 398
Y 179-7644 1 LINES GP-BOOM CYLINDER (LH) 472
Y-SEPARATE ILLUS
TRATION
<END>
259-0838 CYLINDE R & LINES GP- BOO M–RH
S/N: CJN1 -UP
PART OF 330-8777 BOOM AR , 260-6979, 301-2575 BOOM AR-1 PIECE LONG, 301-2479,
301-2517 SPECIAL AR
AN ATTACHMENT
SMCS-5456, 7562 i03195682
NOTE PART NUMBER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
Y 259-0839 1 CYLINDER & SEAL GP-BOOM 398
Y 179-7645 1 LINES GP-BOOM CYLINDER (RH) 473
Y-SEPARATE ILLUSTRATION
<END>
289-8090 CYLINDER & LINES GP–LH
S/N: CJN1 -UP
PART OF 283-9001 BOOM AR-1 PIECE LONG
AN ATTACHMENT
SMCS-5456, 7562 i02793516
NOTE PART NUMBER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
Y 289-8092 1 CYLINDER & SEAL GP 399
Y 179-7644 1 LINES GP-BOOM CYLINDER 472
Y-SEPARATE ILLUSTRATION
<END>
289-8091 CYLINDER & LINES GP–RH
S/N: CJN1 -UP
PART OF 283-9001 BOOM AR-1 PIECE LONG
AN ATTACHMENT
SMCS-5456, 7562 i02793519
NOTE PART NUMBER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
Y 289-8092 1 CYLINDER & SEAL GP 399
Y 179-7645 1 LINES GP-BOOM CYLINDER 473
Y-SEPARATE ILLUSTRATION
<END>
