CAT 315 Part Manual Page 696

Part Manual
HYDRAULIC SYSTEM
260-8205 TANK &
FILTER GP-HYDRAULIC
S/N: CJN1 -UP
185-L (48.9-US
GAL)
PART OF 260-8203
TANK & MTG GP-HYDRAULIC
SMCS-5056, 5068 i03093849
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 4B-7739 2 PLUG-DRAIN (HYDRAULIC TANK)
21 4I-5394 1 SENDER AS-TEMPERATURE (HYDRAULIC OIL)
M14I-5490 2 SCREW-MACHINE (M4X0.7X6-MM)
1 095-0826 2 LOCKWASHER
31 8H-9819 1 ADAPTER-PLUG
41 170-9419 1 SWITCH AS-PRESSURE (HYDRAULIC OIL)
1 2M-9780 1 SEAL-O-RING
1 4I-0754 1 SEAL-O-RING
1 8T-8729 2 PIN-CONNECTOR (16-GA TO 18-GA)
1 102-8802 1 KIT-RECEPTACLE (2-PIN)
(INCLUDES RECEPTACLE AS & WEDGE)
51 179-7541 1 PIPE AS
61 213-0677 1 SWITCH AS-LIQUID LEVEL (HYDRAULIC TANK)
1 102-8802 1 KIT-RECEPTACLE (2-PIN)
(INCLUDES RECEPTACLE AS & WEDGE)
1 144-1636 2 PIN-CONNECTOR (14-GA TO 18-GA)
71 227-0590 1 BREATHER GP (HYDRAULIC TANK)
Y8 1 227-0620 1 GAUGE GP-SIGHT (HYDRAULIC OIL LEVEL) 448
Y9 1 259-0869 1 FILTER GP-OIL (HYDRAULIC, MAIN RETURN) 444
Y10 1 259-0920 1 SCREEN GP-HYDRAULIC (TANK) 657
12 1 269-9853 1 COVER AS
13 1 269-9855 1 FLANGE AS
1 270-0034 1 SEAL-O-RING
14 1 269-9858 1 PIPE
Y15 1 289-8194 1 FILTER GP-OIL (HYDRAULIC, CASE DRAIN) 446
16 1 292-7461 1 SUPPORT
17 1 207-6403 1 PLUG
18 1 207-6404 1 WASHER (49.5X60.5X1.5-MM THK)
19 1 095-1608 1 SEAL-O-RING
20 1 095-1725 1 SEAL-O-RING
21 1 129-3400 1 GUARD
Y22 1 158-8987 1 FILTER & VALVE GP-PILOT (HYDRAULIC OIL) 438
23 1 164-5567 1 COUPLER AS-QUICK DISCONNECT
1 3J-1907 1 SEAL-O-RING
1 6V-3965 1 FITTING (QUIC
K DISCONNECT)
24 1 164-5590 1 VALVE AS-FLUID SAMPLING (HYDRAULIC OIL)
1 3J-7354 1 SEAL-O-RING
1 8C-3446 1 VALVE-FLUID SAMPLING
25 1 1J-2859 1 SEAL-O-RING
26 1 2B-0858 1 PLUG-PIPE
27 1 2H-3934 1 SEAL-O-RING
28 1 3D-2824 1 SEAL-O-RING
29 1 3K-0360 1 SEAL-O-RING
30 1 4J-0527 1 SEAL-O-RING
31 1 4J-5267 1 SEAL-O-RING
M32 1 5C-9553 4 BOLT (M6X1X16-MM)
33 1 6V-0852 1 CAP-DUST
34 1 8C-3451 1 CAP-DUST
M35 1 191-8920 2 BOLT-SOCKET HEAD (M6X1X12-MM)
M36 1 170-8553 4 BOLT-SOCKET HEAD (M12X1.75X40-MM)
37 1 8T-4121 13 WASHER-HARD (11X21X2.5-MM THK)
M38 1 8T-4136 7 BOLT (M10X1.5X25-MM)
M39 1 8T-4137 1 BOLT (M10X1.5X20-MM)
M40 1 8T-4184 8 BOLT (M12X1.75X45-MM)
41 1 8T-4223 8 WASHER-HARD (13.5X25.5X3-MM THK)
666 HYDRAULIC SYSTEM 1of3 SEBP 4861-02
