CAT 315 Part Manual Page 622

Part Manual
HYDRAULIC SYSTEM
302-3195 LINES GP-PILOT (contd. ) i03148224
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
2 6V-8397 1 SEAL-O-RING
2 8T-1905 1 ELBOW
65 2 164-8908 1 CONNECTOR AS
2 3K-0360 1 SEAL-O-RING
2 6V-8398 1 SEAL-O-RING
2 8T-0077 1 CONNECTOR
66 3 164-5629 1 FITTING AS
3 3J-1907 1 SEAL-O-RING
3 108-7516 1 FITTING
67 1 5P-2369 1 CLIP
68 1 5P-7462 1 CLIP (SLOT)
69 1 5P-7463 1 CLIP (TAB)
70 3 164-6874 1 FITTING AS-ELBOW
3 3J-1907 1 SEAL-O-RING
3 085-7356 1 FITTING
71 1 6V-0683 1 GROMMET
72 3 6V-8397 2 SEAL-O-RING
73 3 6V-9829 1 CAP AS
74 3 7X-0613 2 WASHER-HARD (8.8X2
5.5X5-MM THK)
75 1,2 8T-4121 6 WASHER-HARD (11X21X2.5-MM THK)
M761,2 8T-4136 5 BOLT (M10X1.5X25-MM)
M77 2 8T-4137 1 BOLT (M10X1.5X20-M
M)
M78 2 8T-4183 4 BOLT (M12X1.75X40-MM)
M79 3 8T-4189 2 BOLT (M8X1.25X20-MM)
80 2 8T-4223 6 WASHER-HARD (13.5X
25.5X3-MM THK)
81 3 8T-4224 2 WASHER-HARD (8.8X16X2-MM THK)
M82 3 8T-4908 2 BOLT (M8X1.25X25-MM)
M83 2 8T-4956 2 BOLT (M12X1.75X35-M
M)
M84 3 8T-6869 2 BOLT (M8X1.25X60-MM)
85 3 164-5567 1 COUPLER AS-QUICK DISCONNECT
3 3J-1907 1 SEAL-O-RING
3 6V-3965 1 FITTING (QUICK DISCONNECT)
86 3 148-8443 1 TEE AS
3 3J-1907 1 SEAL-O-RING
3 6V-8397 1 SEAL-O-RING
3 7X-2459 1 TEE-O-RING
I87 2 087-4532 1 HOSE AS
88 3 6V-0852 1 CAP-DUST
E-ORDER BY THE CENTIMETER
I-REFER TO HYDRAULIC INFORMATION SYSTEM
M-METRIC PART
Y-SEPARATE ILLUSTRATION
592 HYDRAULIC SYSTEM 3of7 SEBP 4861-02
