CAT 315 Part Manual Page 531

Part Manual
HYDRAULIC SYSTEM
260-8222 LINES
GP-FRONT
–QUICK COUPLER
S/N: CJN1 -UP
PART OF 262-324
9 CONTROL AR-COUPLER
AN ATTACHMENT
TYPE 3
SMCS-5057 i03026101
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 148-8336 1 CONNECTOR AS
1 3J-1907 1 SEAL-O-RING
1 6V-8397 1 SEAL-O-RING
1 6V-8636 1 CONNECTOR
22 3S-2093 1 STRAP-CABLE
31 4I-9521 4 BAND-MARKER (RED, L1)
41 4I-9522 4 BAND-MARKER (YELLOW, L2)
51 9X-6582 2 NUT (13/16-16-THD)
61 292-7635 1BOSS
I7 2 123-2790 1HOSEAS
M8 2 8T-4910 2 BOLT (M12X1.75X60-MM)
10 2 236-3200 1 SUPPORT AS
C11 2 328-2035 1 VALVE GP-SOLENOID & MANIFOLD (QUICK COUPLER)
2 260-3883 1 COIL AS-SOLENOID
2 1S-9593 2 STRAP-CABLE
2 186-3735 2 PIN-CONNECTOR (16-GA TO 18-GA)
2 230-4012 1 RECEPTACLE AS-CONNECTOR (2-PIN)
12 1 266-0982 1 GUARD
I13 1 307-4943 2HOSEAS
I14 2 285-2906 1HOSEAS
15 2 148-8368 2 ELBOW AS
(EACH INCLUDES)
2 3J-1907 1 SEAL-O-RING
2 4J-5477 1 SEAL-O-RING
2 6V-8627 1 ELBOW
16 2 285-2663 2 FITTING AS (QUICK DISCONNECT, MALE)
(EACH INCLUDES)
2 3J-1907 1 SEAL-O-RING
2 285-2664 1 FITTING
17 2 148-8378 2 ELBOW AS
(EACH INCLUDES)
2 3J-1907 1 SEAL-O-RING
2 6V-8397 1 SEAL-O-RING
2 6V-8724 1 ELBOW
18 2 164-6874 3 FITTING AS-ELBOW (QUICK DISCONNECT, MALE)
(EACH INCLUDES)
2 3J-1907 1 SEAL-O-RING
2 085-7356 1 FITTING
19 1 148-8419 2 REDUCER AS
(EACH INCLUDES)
1 4J-5477 1 SEAL-O-RING
1 6V-8935 1 REDUCER-O-RING
20 2 150-4027 1TEEAS
2 3J-1907 1 SEAL-O-RING
2 3E-2310 1TEE
2 6V-8397 1 SEAL-O-RING
21 2 164-5567 1 COUPLER AS-QUICK DISCONNECT
2 3J-1907 1 SEAL-O-RING
2 6V-3965 1 FITTING (QUICK DISCONNECT)
22 1,2 8T-4223 3 WASHER-HARD (13.5X25.5X3-MM THK)
M23 1 8T-4648 1 BOLT (M12X1.75X70-MM)
24 1 5P-7468 1 CLIP (SLOT)
25 1 5P-7469 1 CLIP (TAB)
26 2 6V-0852 1 CAP-DUST
SEBP4861-02 1of4 HYDRAULIC SYSTEM 501
