CAT 315 Part Manual Page 16

Part Manual
MAINTENANCE PARTS
DESCRIPTION
PART
NUMBER QTY WHERE USED PAGE
HYDRAULIC SYSTEM
BREATHER (SWING DRIVE) 4H-6112 1 DRIVE GP-SWING 432
1 DRIVE GP-SWING 433
1 DRIVE GP-SWING 434
BREATHER AS 267-6744 1 DRIVE GP-SWING 432
1 DRIVE GP-SWING 433
1 DRIVE GP-SWING 434
BREATHER GP (HYDRAULIC TANK) 227-0590 1 TANK & FILTER GP-HYDRAULIC 666
FILTER ELEMENT AS-OIL (HYDRAULIC) 216-6676 1 FILTER GP-OIL 443
266-7796 1 FILTER GP-OIL 445
FILTER-OIL (ADVANCED EFFICIENCY)
(HYDRAULIC)
5I-8670 1 FILTER & VALVE GP-PILOT 439
FILTER-OIL (ADVANCED EFFICIENCY)
(HYDRAULIC, CASE DRAIN)
093-7521 1 FILTER GP-OIL 446
FILTER-OIL (ADVANCED EFFICIENCY)
(HYDRAULIC, PILOT)
5I-8670 1 FILTER & VALVE GP-PILOT 441
FILTER-OIL (ULTRA HIGH E FFICIENCY)
(HYDRAULIC, PILOT)
126-1813 1 FILTER & VALVE GP-PILOT 440
PLUG-DRAIN (HYDRAULIC TANK) 4B-7739 2 TANK & FILTER GP-HYDRAULIC 666
SCREEN AS (HYDRAULIC TANK) 209-6002 1 SCREEN GP-HYDRAULIC 657
LUBRICATION SYSTEM
BREATHER (CRANKCASE) 5I-7725 1BREATHERGP 42
FILTER AS-ENGINE OIL
(STANDARD EFFICIENCY)
1R-0739 1 FILTER & MTG GP-ENGINE OIL 43
1 FILTER & MTG GP-ENGINE OIL 46
OPERATOR STATION
BLADE AS-WIPER (275-MM) (LOWER) 4I-5021 1 WIPER & WASHER GP-WINDOW 1073
BLADE AS-WIPER (600-MM) (UPPER) 161-3670 1 WIPER GP-WINDOW 1076
CAP AS (WINDOW WASHE R) 178-5431 1 WASHER GP-WINDOW 1055
FILTER ELEMENT-CAB AIR 293-1184 1 DUCT GP-CAB AIR 939
FILTER ELEMENT-CAB AIR
(AIR CONDITIONER)
245-7823 1 AI R CONDITIONER GP 848
1 AI R CONDITIONER GP 851
FUSE (5-AMPERE) (RADIO) 141-2759 1 INSTALLATION GP-RADIO 982
LAMP (24-VOLT, 10-WATT) (DOME) 201-4417 1 CAB GP 872
1 CAB GP 876
LAMP AS-DOME 176-1986 1 CAB GP 872
1 CAB GP 876
RECEIVER DRYER AS (REFRIGERANT) 176-1902 1 LINES GP-AIR CONDITIONER 990
SEAT BELT GP 327-6540 1 SEAT BELT GP 1021
327-6541 1 SEAT BELT GP 1022
SEAT BELT GP (RETRACTABLE, 3-IN) 235-9020 1 SEAT BELT GP 1019
SEAT BELT GP (RETRACTABLE, 46-MM) 273-5446 1 SEAT BELT GP 1018
V-BELT
(REFRIGERANT COMPRESS OR)
255-3016 1 COMPRESSOR GP-REFRIGERANT 888
A12
MAINTENANCE PARTS SEBP4861-02
