CAT 315 Part Manual Page 275

Part Manual
ELECTRICAL AND STARTING SYSTEM
267-7849 WIRIN
G GP-FI NE SWING
S/N: CJN1 -UP
PART OF 260-707
5 VALVE AR-SWING
AN ATTACHMENT
SMCS-1408 i02752928
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 3S-2093 1 STRAP-CABLE
21 111-4836 3CLIP
31 116-0118 1CLIP
41 238-2212 1 SWITCH AS-ROCKER (FINE SWING)
1 167-3542 1 CONNECTOR-RECEPTACLE
1 167-3543 5 TERMINAL (MALE)
51 267-7704 1 BRACKET
61 267-7850 1 HARNESS AS-VALVE
1 155-2270 1 KIT-CONNECTING P
LUG (2-PIN)
(INCLUDES PLUG AS, WEDGE & INTERFACE SEAL)
1 230-4011 1 PLUG AS-CONNECTOR (2-PIN)
71 132-5789 1CLIP
81 6G-2263 2 SPACER (10.5X19X28.5-MM THK)
M9 1 7X-2621 1 BOLT (M10X1.5X12-MM)
10 1 8T-4121 6 WASHER-HARD (11X
21X2.5-MM THK)
M11 1 8T-4133 1 NUT (M10X1.5-THD)
M12 1 8T-4182 2 BOLT (M10X1.5X45-MM)
M13 1 8T-4191 1 BOLT (M10X1.5X16-
MM)
M14 1 8T-4195 1 BOLT (M10X1.5X30-MM)
M-METRIC PART
GRAPHIC #1 <E
ND>
g01382011
SEBP4861-02 1of1 ELECTRICAL AND STARTING SYSTEM 245
