CAT 315 Part Manual Page 902

Part Manual
OPERATOR STATION
235-8910 CAB GP
–EXTERIOR
S/N: CJN1 -UP
PART OF 229-909
7, 229-9099, 229-9101, 316-8815 CAB GP
AN ATTACHMENT
TYPE 1
SMCS-7301, 7325 i02909131
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
12 139-7126 1 HOLDER
22 139-7127 1 HOLDER
31 156-6599 1 STRIKER
42 161-3685 1 ROD
51 235-8933 1 HANDLE AS
61 161-3697 1 GUARD
72 164-0523 1 LEVER AS
82 164-0527 1 ROD
Y9 2 164-0528 1 LEVER GP-AIR & TEMP CONTROL 989
10 1 167-7018 1 COVER AS
11 2 167-7042 2 SEAL
12 2 171-7426 1 CABLE AS
13 2 176-1939 1 LEVER AS
M29X-2044 1 SCREW-TRUSS HEAD (M6X1X16-MM)
2 176-1937 1 BRACKET AS
2 176-1938 1 LEVER
14 2 176-1942 1 COVER
15 1 178-5570 2 GROMMET
16 2 185-8196 1 GROMMET
17 2 189-2704 1 SEAL
M181,2 189-3396 5 NUT (M10X1.15-THD)
19 2 189-3409 3 WASHER
20 2 201-4530 1 BRACKET AS
21 2 205-6295 1 LATCH AS
22 1 210-5808 1 SEAL
23 1 235-8912 1 HANDLE AS
M24 1 099-0823 3 SCREW-MACHINE (M6X1X6-MM)
M25 1 127-0580 2 SCREW-FLAT HEAD (M8X1.25X20-MM)
26 2 133-8016 1 PACKING
27 1 156-6617 1 MIRROR
CY 28 1 259-7295 1 BRACKET GP-MIRROR 856
29 2 176-1986 1 LAMP AS-DOME
2 201-4417 1 LAMP (24-VOLT, 10-WATT) (DOME)
30 1 1R-5998 2 LOCKWASHER
M31 1 284-4426 1 BOLT-WING (M8X1.25X15-MM)
M32 2 3E-8020 6 SCREW-TRUSS HEAD (M6X1X25-MM)
M33 2 3E-9874 2 SCREW-OVAL HEAD
34 1 4I-1205 2 BUMPER
35 2 4I-1206 2 GUIDE
36 2 4I-3063 1 SPRING
M37 1 4I-3123 2 BOLT (M10X1.5X20-MM)
38 1 4I-3144 2 WASHER-HARD (10.2X22X3.2-MM THK)
39 2 4I-4270 1 HOLDER-GLASS
40 2 4I-4392 3 CLIP
41 2 5C-7793 1 HOOK-COAT
42 2 6V-7636 4 PIN AS-SPRING
43 1 7X-0578 2 WASHER-HARD (10.2X32X2.5-MM THK)
–OR–
1 099-3607 2 WASHER-HARD (10.2X30X3.2-MM THK)
CM 44 1 8T-4779 1 BOLT (M16X2X35-MM)
M45 2 9X-2041 1 SCREW-TRUSS HEAD (M10X1.5X20-MM)
M46 2 9X-2042 5 SCREW-TRUSS HEAD (M6X1X12-MM)
M47 2 9X-2044 5 SCREW-TRUSS HEAD (M6X1X16-MM)
M48 2 9X-2045 2 SCREW-TRUSS HEAD (M6X1X20-MM)
872 OPERATOR STATION 1of4 SEBP 4861-02
