CAT 315 Part Manual Page 1076

Part Manual
OPERATOR STATION
229-9077 SUSPE
NSION GP-SEAT
S/N: CJN1 -UP
PART OF 229-907
5, 229-9089 SEAT GP-SUSPENSION
AN ATTACHMENT
SMCS-7324 i02177429
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 242-8768 1 COVER AS
1 147-4921 1 KIT-CLIP (SEAT)
21 245-7889 1 ADJUSTER GP-SE
AT (UPPER SLIDE)
M15C-7261 8 NUT (M8X1.25-THD)
1 8T-4224 8 WASHER-HARD (8.8X16X2-MM THK)
1 245-7897 4 PLATE
M1245-7899 4 SCREW-BUTTON HEAD (M8X1.25X30-MM)
31 245-7890 1 BRACKET GP-MOUNTING
M15C-7261 4 NUT (M8X1.25-THD
)
1 8T-4224 4 WASHER-HARD (8.8X16X2-MM THK)
1 245-7897 4 PLATE
M1245-7899 4 SCREW-BUTTON HEA
D (M8X1.25X30-MM)
Y4 1 245-7892 1 SUSPENSION GP-SEAT 1048
51 245-7895 1 KIT-CLIP (SUSPENSION SEAT)
Y6 1 245-7896 1 ADJUSTER GP-SEAT
(LOWER SLIDE)
842
M-METRIC PART
Y-SEPARATE ILLUSTRATION
GRAPHIC #1 <END> g01087842
1046 OPERATOR STATION 1of1 SE BP 4861-02
