CAT 315 Part Manual Page 942

Part Manual

Page of 1181

/ 1181

OPERATOR STATION

170-9497 CONTR

OL GP-H YDRA ULIC PEDAL

–TRAVEL

S/N: CJN1 -UP

PART OF 259-719

3 OPERATOR AR

SMCS-5059, 5063 i02997569

NOTE

REF

GRAPHIC

REF PART NUM BER QTY

PART NAM E

123456(PRODUCT LEVEL

)

SEE

PAGE

11 096-6166 2 WASHER-HARD (4.5X9X1-MM THK)

M2 1 095-0728 2 SCREW-MACHINE (M4X0.7X12-MM)

31 8T-4121 12 WASHER-HARD (1

1X21X2.5-MM THK)

M4 1 8T-4136 4 BOLT (M10X1.5X25-MM)

M5 1 8T-4191 8 BOLT (M10X1.5X16-MM)

61 142-5546 2 KNOB

71 117-6356 2 STEP AS

81 122-9610 2 STEP

91 170-9499 1 LEVER AS (LH)

10 1 170-9498 1 LEVER AS (RH)

11 1 122-9608 1 PEDAL-RUBBER (RH)

12 1 117-6350 1 PEDAL AS (RH)

13 1 122-9609 1 PEDAL-RUBBER (LH)

14 1 117-6349 1 PEDAL AS (LH)

M-METRIC PART

GRAPHIC #1 <END> g00672963

912 OPERATOR STATION 1of1 SEBP 4861-02
