CAT 315 Part Manual Page 253

Part Manual
ELECTRICAL AND STARTING SYSTEM
267-7642 WIRIN
G GP -CAB
–COUPLER
S/N: CJN1 -UP
PART OF 268-725
3 CONTROL AR-COUPLER
AN ATTACHMENT
SMCS-1408, 7301 i02706844
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 7K-1181 13 STRAP-CABLE
21 149-5050 1 RELAY (24-VOLT) (QUICK COUPLER LOCK PRIORITY)
2A 1 149-5050 1 RELAY (24-VOLT
) (QUICK COUPLER LOCK ON)
2B 1 149-5050 1 RELAY (24-VOLT) (QUICK COUPLER LOCK)
2C 1 149-5050 1 RELAY (24-VOLT) (QUICK COUPLER LOCK)
31 259-4884 1 BRACKET AS
41 259-7220 1 COVER
51 267-7644 1 HARNESS AS-QUICK COUPLER
1 102-7965 3 TERMINAL (FEMALE
)
E1125-7874 TUBE-HEAT SHRINK (5.72-MM DIA) (10-CM)
E1125-7875 TUBE-HEAT SHRINK (7.44-MM DIA) (15-CM)
1 149-5070 9 TERMINAL (FEMALE
)
1 163-6803 1 CONNECTOR-PLUG
1 230-5008 1 PLUG AS-CONNECTOR (4-PIN)
1 7Y-3950 2 TERMINAL (MALE)
1 7Y-3953 1 CONNECTOR-RECEPTACLE
1 149-5069 7 TERMINAL (FEMALE)
1 3S-2093 15 STRAP-CABLE
1 230-5008 1 PLUG AS-CONNECTOR (4-PIN)
61 267-7671 1 SWITCH GP-TOGGLE (QUICK COUPLER)
1 105-5175 1 SWITCH AS-TOGGLE (
QUICK COUPLER)
1 3L-8187 6 LOCKWASHER
1 6T-3631 2 NUT-HEX (15/32-32-THD)
1 6T-3632 1 LOCKWASHER
1 6T-3633 1 RING-LOCKING
1 6V-8374 6 SCREW-MACHINE (6-32X0.25-IN)
1 267-7672 1 HARNESS AS-WIRING (
CAB)
1 3S-2093 1 STRAP-CABLE
1 121-1173 3 TERMINAL
1 167-3542 1 CONNECTOR-RECEPTA
CLE
71 267-7676 1 BRACKET AS
M8 1 9X-2042 7 SCREW-TRUSS HEAD (M6X1X12-MM)
E-ORDER BY THE CENTIMET
ER
M-METRIC PART
SEBP4861-02 1of2 ELECTRICAL AND STARTING SYSTEM 223
