CAT 315 Part Manual Page 548

Part Manual
HYDRAULIC SYSTEM
260-8236 LINES
GP-FRONT
S/N: CJN1 -UP
PART OF 259-756
9 CONTROL AR-AUXILIARY
AN ATTACHMENT
SMCS-5057 i02911216
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 7K-1181 1 STRAP-CABLE
I2 1 115-3796 1 HOSE AS
31 153-8867 2 CLIP
41 178-5883 1 FITTING
I5 1 183-1756 1 HOSE AS
I6 1 196-0590 1 HOSE AS
71 196-0842 1 TUBE AS
81 196-0843 1 TUBE AS
I9 1 275-1586 1 HOSE AS
I10 1 278-6619 1 HOSE AS
11 1 282-7123 1 SUPPORT AS
I12 1 296-6986 1 HOSE AS
13 1 148-8328 1 CONNECTOR AS
1 3D-2824 1 SEAL-O-RING
1 6V-8398 1 SEAL-O-RING
1 6V-8633 1 CONNECTOR
14 1 148-8339 1 CONNECTOR AS
1 6V-8716 1 CONNECTOR
1 6V-9746 1 SEAL-O-RING
1 7M-8485 1 SEAL-O-RING
15 1 148-8364 2 ELBOW AS
(EACH INCLUDES)
1 3K-0360 1 SEAL-O-RING
1 6V-8398 1 SEAL-O-RING
1 6V-8625 1 ELBOW
16 1 148-8418 2 REDUCER AS
(EACH INCLUDES)
1 6V-8398 1 SEAL-O-RING
1 6V-8942 1 REDUCER-O-RING
17 1 148-8444 1 TEE AS-SWIVEL
1 6V-8398 2 SEAL-O-RING
1 6V-9837 1 TEE-SWIVEL
18 1 153-6241 2 ELBOW AS
(EACH INCLUDES)
1 6V-8398 1 SEAL-O-RING
1 8C-8989 1 ELBOW
19 1 153-6242 1 CONNECTOR AS
1 6V-9746 1 SEAL-O-RING
1 7M-8485 1 SEAL-O-RING
1 8T-0197 1 CONNECTOR
20 1 3K-0360 1 SEAL-O-RING
21 1 6V-8398 4 SEAL-O-RING
M22 1 8T-4184 2 BOLT (M12X1.75X45-MM)
23 1 8T-4223 4 WASHER-HARD (13.5X25.5X3-MM THK)
M24 1 8T-4956 2 BOLT (M12X1.75X35-MM)
25 1 9X-6580 2 NUT (1-3/16-12-THD)
I-REFER TO HYDRAULIC INFORMATION SYSTEM
M-METRIC PART
518 HYDRAULIC SYSTEM 1of2 SEBP 4861-02
