CAT 315 Part Manual Page 745

Part Manual
HYDRAULIC SYSTEM
310-0415 VALVE
GP-PILOT
–WITHOU T SHUTTLE
S/N: CJN993-UP
PART OF 275-171
5 LINES GP-PILOT
SMCS-5059 i03127888
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 087-5708 2 PEDAL
M2 1 095-0673 2 BOLT-SOCKET HEAD (M12X1.75X60-MM)
31 099-6137 4 WASHER (6.1X9X
0.2-MM THK)
41 099-6141 4 WASHER (6.1X11X1.5-MM THK)
51 099-6144 4 BUSHING-TERMINAL
61 099-6145 2 CAMSHAFT
71 119-5388 4CAP
81 119-5389 4 PACKING
91 119-5391 4SEAT
10 1 126-1865 4 SPRING
11 1 126-1866 4 SPRING
12 1 131-5818 4 SPRING
13 1 147-4131 2 BOOT-PROTECTION
14 1 153-5223 12 BALL
15 1 165-9463 2 COVER
16 1 165-9552 4 PUSHROD
17 1 165-9553 1 COVER
18 1 165-9554 4PLUG
19 1 270-5949 4 PISTON
20 1 270-5950 4 SPRING
21 1 310-0419 4SEAT
22 1 310-0420 4 SEAL-O-RING
M23 1 087-4710 4 SETSCREW
M24 1 095-1260 2 SETSCREW-SOCKET (M
6X1X6-MM)
25 1 095-1575 2 SEAL-O-RING
26 1 6V-8400 4 SEAL-O-RING
M27 1 8C-6965 2 BOLT-SOCKET HEAD (M
6X1X45-MM)
M28 1 8T-1158 2 BOLT-SOCKET HEAD (M8X1.25X20-MM)
M29 1 8T-4133 4 NUT (M10X1.5-THD)
M-METRIC PART
SEBP4861-02 1of2 HYDRAULIC SYSTEM 715
