CAT 315 Part Manual Page 1089

Part Manual
OPERATOR STATION
139-7101 WINDO
W GP -CAB
–FRONT, UPPER
S/N: CJN1 -UP
PART OF 229-909
7, 229-9099, 229-9101, 316-8815 CAB GP
AN ATTACHMENT
SMCS-7310 i02836457
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
12 170-9722 1 CUSHION
21 151-6703 1 HANDLE-PULL
31 151-6704 2 CAP (HANDLE)
42 151-6778 1 FRAME AS
51 151-6785 1 BRACKET AS
61 151-6813 1 BRACKET AS
71 151-6815 1 BRACKET AS
81 273-5345 1LINKAS
91 273-5346 1LINKAS
10 1 151-6831 1LOCKAS
11 1 151-6832 1 LEVER AS
12 2 151-6844 1 COVER
13 1 151-9557 2 STOP-RUBBER
14 2 156-6472 1 GLASS
15 2 156-6554 1 CABLE AS
16 1 156-6555 1 STRIKER AS
17 2 156-6562 1 BRACKET
18 2 273-5274 1 CATCH AS
19 2 156-6579 1STOP
20 2 156-6601 1SEALAS
21 2 156-6627 1STOPAS
22 1 161-3684 2STOP
23 1 161-3698 1SEAL
24 2 164-0648 1 BRACKET AS
25 1 178-5576 1STOP
M26 2 185-8181 2 SCREW (M4X0.7X10-MM)
M27 2 185-8182 4 BOLT (M10X1.5X20-M
M)
M28 2 5C-8312 1 NUT (M4X0.7-THD)
29 2 185-8187 4 WASHER (10.2X22X3.2-MM THK)
M30 1 185-8197 1 NUT (M10X1.15-THD)
31 1 185-8221 1STOP
M32 1 099-0823 2 SCREW-MACHINE (M6X1X6-MM)
M33 1 101-8900 2 SCREW AS (M6X1X20-MM
)
34 1 117-6306 1 SWITCH (WINDOW LOWER LIMIT)
35 1 151-9576 4 ROLLER
36 1 4I-0420 1 STRIP
37 1 7X-0578 1 WASHER-HARD (10.2X32X2.5-MM THK)
M38 2 9X-2042 20 SCREW-TRUSS HEAD (M6X1X12-MM)
M391,2 9X-2044 5 SCREW-TRUSS HEAD (M6X
1X16-MM)
M40 2 9X-2045 3 SCREW-TRUSS HEAD (M6X1X20-MM)
41 2 9X-8256 2 WASHER (6.6X12X2-MM THK)
M-METRIC PART
SEBP4861-02 1of3 OPERATOR STATION 1059
