CAT 315 Part Manual Page 460

Part Manual
HYDRAULIC SYSTEM
199-4602 DRIVE
GP-SWING
–WITHOUT MOTOR
S/N: CJN1 -UP
PART OF 199-460
0, 267-6779 DRIVE GP-SWING
ALSO AN ATTACHME
NT
SMCS-5459 i01823301
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 191-2600 3 GEAR-PLANETARY
21 191-2599 1 CARRIER-PLANETARY
31 191-2604 3 PIN-SPRING
41 191-2603 3 SHAFT-PLANETARY
51 199-4628 3 SHAFT-PLANETARY
61 191-2605 1 WASHER (30X75X3
-MM THK)
71 199-4629 1 GEAR-SUN
81 199-4630 1 GEAR-SUN
M9 1 114-8224 1 BOLT (M20X1.5-TH
D)
10 1 199-4631 1 GEAR-RING
11 1 093-6089 2 DOWEL
12 1 095-0893 1 PIN-SPRING
13 1 7I-7625 1 BEARING AS-ROLLER
14 1 199-4638 1 HOUSING
15 1 199-4632 1 SHAFT-PINION
16 1 199-4636 1 SPACER
17 1 199-4627 6 WASHER
18 1 199-4634 1 SPACER
19 1 199-4635 1 SPACER
20 1 199-4637 1 SPACER
21 1 148-4744 1 BEARING AS
M22 1 8T-4195 9 BOLT (M10X1.5X30-MM)
23 1 8T-4121 9 WASHER-HARD (11X21X2.5-MM THK)
24 1 102-6495 1 SEAL
25 1 148-4748 1 CAGE
26 1 148-4747 1 SPACER (29.5-MM THK)
B27 1 1U-8846 1 SEALANT-GASKET
28 1 148-4751 1 SPACER (8.3-MM THK)
B1148-4752 1 SPACER (8.275-MM THK)
B1148-4754 1 SPACER (8.25-MM THK
)
B1148-4755 1 SPACER (8.225-MM THK)
B1148-4756 1 SPACER (8.2-MM THK)
B1148-4757 1 SPACER (8.175-MM THK
)
B1148-4758 1 SPACER (8.15-MM THK)
B1148-4759 1 SPACER (8.125-MM THK)
B1148-4760 1 SPACER (8.1-MM THK)
B1148-4761 1 SPACER (8.075MM THK)
B1148-4762 1 SPACER (8.05-MM THK)
B1148-4763 1 SPACER (8.025-MM THK)
B1148-4764 1 SPACER (8-MM THK)
B1169-5520 1 SPACER (7.95-MM THK)
B1169-5521 1 SPACER (7.9-MM THK)
B1169-5522 1 SPACER (7.85-MM THK)
B1169-5523 1 SPACER (7.8-MM THK)
29 1 199-4624 1 CARRIER-PLANETARY
30 1 114-8223 1 RETAINER
31 1 8C-3347 3 PIN-ROLL
32 1 191-2602 6 WASHER (32X56X1.2-MM T
HK)
33 1 191-2601 3 BEARING
34 1 199-4625 3 GEAR-PLANETARY
35 1 199-4626 3 BEARING
B-USE AS REQUIRED
M-METRIC PART
430 HYDRAULIC SYSTEM 1of2 SEBP 4861-02
