SUPPLEMENTAL C OOLANT ADDITIVES

CUSTOMER BENEF

ITS:

Protects again

st cavitation, foam, erosion, corrosion, and scale buildup in cooling systems.

• Provides measu

red coolant conditioner.

DESCRIPTION:

Additives dep

lete from the coolant with normal operation. For this reason, Supplemental Coolant Additives (SCA) must

be added to all

heavy duty coolants at regular intervals. In addition, when not using a fully formulated, pre-charged

antifreeze, l

ike Caterpillar’s DEAC, an initial charge of SCA must be added to the cooling system. The amount of SCA

added to the sy

stem is dependent on the capacity of the system.

The SCA for ini

tial ﬁll is provided as a liquid. SCA’s for maintenance intervals are available in liquid form and as a

spin-on eleme

nt. (No Spin-on available for 3600 Family of Engines)

NOTE:

The amount of S

CA added at initial ﬁll is not the same as the amount added at maintenance intervals.

The coolant ad

ditive elements can be used with any ethylene or propylene glycol type antifreeze which meets ASTM

D4985 or ASTM

D5345 Speciﬁcations.

NOTE:

For use with s

tandard heavy duty coolant only, not for use with Extended Life Coolant.

PARTS NEEDED

Cooling System Capacity

Liters Gallons

Liquid SCA at Initial Fill

Liquid SCA at

Maintenance*

Spin-on SCA

Maintenance Element*

22-30 (6-8) 3P-2044 (1) 6V-3542 (1) 111-2370 (1)

30-38

(8-10)

3P-2044 (1)

6V-3542 (1)

111-2372 (1) 111-2369 (1)

38-49 (10-13)

3P-2044 (1)

8T-1589 (1)

111-2372 (1) 111-2369 (1)

49-64 (13-17) 3P-2044 (2) 8T-1589 (1) 9N-3368 (1)

64-83

(17-22)

3P-2044 (2)

8T-1589 (1)

111-2372 (1)

6V-3542 (1)

11 1-2371 (1)

83-114 (22-30)

3P-2044 (3)

8T-1589 (1)

3P-2044 (1) 9N-3718 (1)

114-163

(30-43) 3P-2044 (5)

3P-2044 (1)

6V-3542 (1)

11 1-2371 (2)

163-242 (43-64) 3P-2044 (8) 3P-2044 (2) 9N-3718 (2)

* Normal maintenance period is 250 hrs. See your Operation and Maintenance Manual for complete coolant

maintenance instructions.

( ) Indicates quantity required.

SEBP4861-02 SUPPLEME NTAL COOLANT ADDITIVES A9
