CAT 315 Part Manual Page 252

Part Manual
ELECTRICAL AND STARTING SYSTEM
259-5165 WIRIN
G GP-C AB
–SYSTEM 20, WORK TOOL PRIORITY
S/N: CJN1 -UP
PART OF 259-755
7 CONTROL AR-AUXILIARY
AN ATTACHMENT
SMCS-1408, 7301 i02747389
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 3S-2093 7 STRAP-CABLE
21 7K-1181 10 STRAP-CABLE
31 149-5050 1 RELAY (24-VOLT
) (WORK TOOL)
41 259-7219 1 COVER
51 267-7692 1 HARNESS AS-PUMP
1 3S-2093 14 STRAP-CABLE
E1125-7874 TUBE-HEAT SHRINK (5.72-MM DIA) (5-CM)
1 243-4508 1 RECEPTACLE AS-CONNECTOR (6-PIN)
61 267-7693 1 SWITCH GP-TOGGLE
(WORK TOOL PRIORITY)
1 7N-2353 1 SWITCH AS-TOGGLE (WORK TOOL PRIORITY)
1 267-7694 1 HARNESS AS-CONTROL
1 3S-2093 1 STRAP-CABLE
71 267-7695 1 BRACKET AS
M8 1 5C-2890 1 NUT (M6X1-THD)
M9 1 9X-2042 3 SCREW-TRUSS HEAD
(M6X1X12-MM)
10 1 9X-8256 1 WASHER (6.6X12X2-MM THK)
E-ORDER BY THE CENTIMETER
M-METRIC PART
GRAPHIC #1 <END> g01386511
222 ELECTRIC AL AND S TARTING SY STEM 1of1 SEBP 4861-02
