CAT 315 Part Manual Page 910

Part Manual
OPERATOR STATION
235-8917 CAB GP
–INTERIOR
S/N: CJN1 -UP
PART OF 316-881
5 CAB GP
AN ATTACHMENT
SMCS-7301, 7325 i02783571
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 8Y-6352 1 LOUVER AS
21 164-0646 1 CUP
31 164-0655 1 PANEL-SWITCH (
OPERATOR CONSOLE)
41 164-8474 2 LOUVER AS-VENT
51 170-9724 5 CLIP
61 171-7420 10 CLIP
71 176-1972 1 COVER
81 185-8205 7 CLIP
91 185-8214 1 BRACKET AS
10 1 189-2678 3 SPACER
11 1 189-2853 1 COVER
12 1 189-2854 1 COVER
13 1 234-6468 1 COVER AS
1 259-7353 4 CLIP
14 1 234-6470 1 COVER-MONITOR
15 1 234-6471 1 COVER-DUCT
16 1 234-6472 1 COVER
17 1 234-6473 1 COVER-FRONT (UPPE
R, RH)
18 1 234-6474 1 COVER (UPPER, RH)
20 1 234-6476 1 DUCT
21 1 234-6477 1 BRACKET AS
23 1 234-6480 1 BRACKET AS
24 1 234-6483 1 BRACKET AS
25 1 234-6485 1 BRACKET AS
26 1 234-6490 1 CUP
27 1 234-6491 1 COVER
28 1 234-6497 1 COVER
29 1 234-6498 3 RIVET
30 1 234-6521 1 COVER
31 1 234-6547 1 COVER
32 1 234-6548 1 COVER
33 1 234-6549 1 COVER
34 1 234-6550 1 COVER
35 1 234-6579 2 NUT-SPEED
36 1 235-8922 1 COVER
37 1 235-8923 2 CAP
38 1 235-8930 1 LINER
C39 1 235-8950 10 CLIP
40 1 245-7790 2 SCREW-TAPPING
M41 1 128-2135 13 SCREW-TRUSS HEAD (M6X1X13-MM)
M42 1 128-2136 1 SCREW-TRUSS HEAD (M6X1X16-MM)
43 1 189-2855 1 COVER
44 1 234-6469 1 COVER
M45 1 9X-2042 23 SCREW-TRUSS HEAD (M6X1X12-MM)
C46 1 305-0333 1 BRACKET
C47 1 305-0330 1 COVER
C-CHANGE FROM PREVIOUS TYPE
M-METRIC PART
880 OPERATOR STATION 1of2 SEBP 4861-02
