FUEL SYSTEM

278-3711 TANK G

P-FUEL

S/N: CJN1 -UP

300-L (79.3-US

GAL)

PART OF 262-2260

TANK GP-FUEL

SMCS-1273 i02868803

NOTE

REF

GRAPHIC

REF PART NUM BER QTY

PART NAM E

123456(PRODUCT LEVEL

)

SEE

PAGE

11 4I-0378 1 GASKET-RUBBER

21 5P-4924 1 ELBOW

31 164-4858 1 CAP GP-FUEL FIL

LER (EXTREME SERVICE, LOCKABLE)

1 9X-8600 1 SEAL-O-RING

1 190-9775 1 COVER AS-FILTER

41 003-7764 1 END-HOSE

51 128-4411 1 VALVE AS (FUEL SHUTOFF)

61 163-6700 1 SENSOR GP-FUEL LEVEL

1 186-3735 2 PIN-CONNECTOR (1

6-GA TO 18-GA)

1 102-8802 1 KIT-RECEPTACLE (2-PIN)

(INCLUDES RECEPTACLE AS & WEDGE)

J7 1 303-9933 1 STRAINER AS-FUEL (

FLOAT GAUGE)

81 8T-0328 5 WASHER-HARD (5.5X10X1-MM THK)

M9 1 095-0736 5 SCREW-MACHINE (M5X0.8X10-MM)

10 1 3J-1907 1 SEAL-O-RING

AVAILABLE REPAIR K

IT(S):

J 303-9937 1 KIT-GAUGE (FUEL STRAINER)

(INCLUDES STOPPER & GAUGE)

J-KIT MARKED J SERVICE

S PART MARKED J

M-METRIC PART

104 FUEL SYST E M 1of2 SE BP 4861-02
