CAT 315 Part Manual Page 90

Part Manual
COOLING SYSTEM
245-9311 RADIA
TOR & HYD OIL COOLER GP
S/N: CJN1 -UP
PART OF 245-931
0 RADIATOR & HYD OIL COOLER GP
SMCS-1351 i03129822
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
12 5D-8159 4 PIN AS
M2 1 093-5432 1 VALVE AS-DRAIN (COOLANT)
32 096-4035 2 CLIP
42 210-8117 2 SEAL
52 245-9212 1 CAP AS-RADIATOR
62 245-9216 2 BOSS
72 245-9217 2 CUSHION-RUBBER
82 245-9218 2 CUSHION-RUBBER
91 265-3629 1 SEAL
10 1,2 265-3630 2 SEAL
11 1,2 265-3632 3 SEAL
12 2 281-3524 1 CORE AS-RADIATOR
13 2 281-3525 1 CORE AS-OIL COOLER (HYDRAULIC)
14 2 281-3526 1 AFTERCOOLER AS
15 2 281-3527 1 FRAME AS
16 2 281-3528 2 SEAL
17 1 281-3529 1 SHROUD AS-RADIATOR
18 1 281-3530 2 SEAL
19 2 281-3531 1 SCREEN AS (RADIATOR)
20 2 281-3532 1 SCREEN AS (HYDRAULIC OIL COOLER)
21 1 281-3533 2 SHEET-RUBBER
22 1 095-1543 2 SEAL-O-RING
23 2 8T-4121 2 WASHER-HARD (11X21X2.5-MM THK)
M241,2 8T-4189 22 BOLT (M8X1.25X20-M
M)
M25 2 8T-4195 2 BOLT (M10X1.5X30-MM)
26 1,2 8T-4224 22 WASHER-HARD (8.8X16X2-MM THK)
E27 2 7Y-1976 HOSE-WATER (220-CM
)
E27A 1 7Y-1976 HOSE-WATER (8-CM)
E-ORDER BY THE CENTIMETER
M-METRIC PART
60 COOLING SYSTEM 1of3 SEBP 4861-02
