CAT 315 Part Manual Page 729

Part Manual
HYDRAULIC SYSTEM
259-7550 VALVE
GP-MAIN CONTROL
S/N: CJN1 -UP
PART OF 259-754
7 HYDRAULIC AR, 285-1736, 285-1738 VALVE & MTG GP-CONTROL
ALSO AN ATTACHME
NT
SMCS-5051 i02866456
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
13 285-1507 1 SPRING
23 285-1506 1 VALVE
I3 5 275-1504 1HOSEAS
45 285-1503 2 COVER
54 095-1579 1 SEAL-O-RING
M6 1 5A-3604 24 BOLT-SOCKET HEAD (M8X1.25X25-MM)
M7 1 197-0165 20 BOLT (M8X1.25X20-MM)
82 197-0167 1 PLATE
9 2,3,4,5 095-1578 12 SEAL-O-RING
10 2,3,4,5 095-1696 8 SEAL-O-RING
M11 2 104-8107 5 BOLT-SOCKET HEAD (M14X2X55-MM)
12 2,3,4,5 095-1698 18 SEAL-O-RING
13 2,3,4,5 197-0145 14 PLUG
14 2,3,4,5 095-1582 14 SEAL-O-RING
15 2,3,4 095-1585 11 SEAL-O-RING
16 2,3,4 197-0272 8PLUG
M17 3 197-0143 3 BOLT (M14X2X95-MM)
18 2,3 3D-2824 2 SEAL-O-RING
19 2,3 9S-4183 2 PLUG-O-RING
M20 3 197-0144 13 BOLT (M14X2X130-MM)
21 2 7I-7192 2PLUG
22 2 215-4855 2 VALVE AS-CHECK (MAKEUP)
23 2,3,4,5 095-1700 10 SEAL-O-RING
24 2,3,4,5 197-0168 10 COVER
Y 25 1,2,4,5 309-9977 6 VALVE GP-PILOT RELIEF (LINE) 717
26 1,2,3,
4,5
7I-7208 10 VALVE-LOAD CHECK
27 1,2,3,
4,5
7I-0207 13 PLATE
28 1,2,3,
4,5
095-1586 15 SEAL-O-RING
29 1,2,3,
4,5
7I-7206 13 PLUG
Y30 2 259-7868 1 SPOOL GP-CONTROL VALVE (BUCKET CYLINDER) 661
31 2,3,4,5 7I-7204 12 SEAL
32 2,3,4,5 197-0170 10 COVER
Y33 3 285-1667 1 VALVE GP-CONTROL (STICK II) 684
34 3 197-0225 2PLUGAS
Y35 3 197-0173 1 SPOOL GP-CONTROL VALVE (WORK TOOL) 658
Y36 4 310-0074 1 VALVE GP-CONTROL (BOOM II) 688
37 4,5 131-5767 2PLUG
38 4,5 105-7405 2 SPRING
39 4,5 131-5768 2 VALVE-LOAD CHECK
40 1,5 197-0169 2 VALVE AS
Y41 4 310-0072 1 VALVE GP-CONTROL (BOOM I) 687
42 3 7I-7235 2PLUG
43 3 3J-1907 1 SEAL-O-RING
44 3 9S-4191 1 PLUG-O-RING
45 3 309-9960 1 SPOOL AS (STRAIGHT TRAVEL)
46 3 103-8413 1ROD
47 3 103-8412 1 SPRING
48 3 103-8411 1 SPRING
49 3 197-0166 1PLUG
50 3,5 7I-8084 6PLUG
Y513,4 197-0219 2 SPOOL GP-CONTROL VALVE 659
Y52 4 270-5979 1 VALVE GP-RELIEF (MAIN) 720
SEBP4861-02 1of7 HYDRAULIC SYSTEM 699
