CAT 315 Part Manual Page 33

Part Manual
MACHINE ARRANGEMENT
301-2517 SPECIAL AR–ACC UGRADE
S/N: CJN1 -UP
AN ATTACHMENT
SMCS-7000 i02846247
NOTE PART NUMBER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
Y 303-8845 1BOOMGP 758
Y 259-0837 1 CYLINDER & LINES
GP-BOOM (LH)
395
Y 259-0838 1 CYLINDER & LINES GP-BOOM (RH) 395
Y 310-1782 1 CYLINDER & LINES GP-BUCKET 397
Y 259-0841 1 CYLINDER & LINES
GP-STICK
397
Y 297-7558 1 FRAME GP-UPPER 313
Y 295-9562 1 GUARD GP-CYLINDER 449
Y 210-3821 1 GUARD GP-FRONT 319
Y 303-9985 1HOODGP 331
Y 259-5163 1 LIGHTING GP-FLOOD (BOOM, LH) 175
Y 260-8220 1 LINES GP-BOOM 469
Y 174-8529 1 LINES GP-GREASE 762
Y 289-5749 1 LINES GP-PILOT (ACCUGRADE, CAB) 585
Y 289-5750 1 LINES GP-PILOT (AC
CUGRADE, CONTROL VALVE)
587
Y 264-1603 1 LINKAGE GP-BUCKET (WITH LIFTING EYE) 765
Y 297-4469 1 SENSOR & MTG GP-POSITION (BOOM) 191
Y 297-4470 1 SENSOR & MTG GP-POS
ITION (STICK)
192
Y 299-2697 1 WIRING GP-CAB (ACCUGRADE READY) 225
Y 299-2696 1 WIRING GP-CHASSIS 228
Y 299-2698 1 WIRING GP-GRADE CO
NTROL (ACCUGRADE, BOOM)
248
Y 299-2699 1 WIRING GP-GRADE CONTROL (ACCUGRADE, STICK) 250
Y 306-8398 1 WIRING GP-PLATFORM 263
290-9378 1 PANEL-CONTROL (SWITCH)
Y-SEPARATE ILLUSTRATION
<END>
301-2565 SPECIAL AR
S/N: CJN1 -UP
CHINA
FOR USE WITH 500-MM (19.6-IN) TRACK SHOES
AN ATTACHMENT
SMCS-7000 i02852821
NOTE PART NUMBER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
Y 298-4281 1 FILM GP 1089
305-0395 1 HANDLE AS
Y-SEPARATE ILLUSTRATION
<END>
SEBP4861-02 MACHINE ARRANGEMENT 3
