CAT 315 Part Manual Page 617

Part Manual
HYDRAULIC SYSTEM
289-5750 LINES
GP-PILOT
–ACCUGRAD E, CONTROL VAL VE
S/N: CJN1 -UP
PART OF 301-247
9, 301-2517, 330-8775 SPECIAL AR
AN ATTACHMENT
SMCS-5057, 5059 i02843750
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
I1 2 4I-1783 1HOSEAS
I2 2 4I-3991 2HOSEAS
I3 2 4I-5933 1HOSEAS
I4 2 4I-6136 1HOSEAS
51 4I-9521 2 BAND-MARKER (RED, L1)
62 4I-9523 2 BAND-MARKER (BLUE, L3)
72 4I-9525 8 BAND-MARKER (ORANGE, R1)
82 4I-9526 4 BAND-MARKER (WHITE, R2)
92 4I-9527 4 BAND-MARKER (GREEN, R3)
10 2 4I-9528 4 BAND-MARKER (PURPLE, R4)
I11 2 5I-4076 1HOSEAS
12 1,2 7K-1181 5 STRAP-CABLE
I13 2 7Y-4190 1HOSEAS
I14 2 7Y-4193 1HOSEAS
I15 1 102-7685 1HOSEAS
I16 2 104-8783 1HOSEAS
17 2 150-4027 1TEEAS
2 3E-2310 1TEE
2 3J-1907 1 SEAL-O-RING
2 6V-8397 1 SEAL-O-RING
18 2 157-3180 1 SENSOR AS-PRESSURE
2 9X-3401 3 PIN-CONNECTOR (16-GA TO 18-GA)
–OR–
2 126-1767 3 PIN-CONNECTOR (14-GA)
2 171-0596 1 RECEPTACLE AS
2 185-2478 1 SEAL
19 2 164-5546 1TEEAS
2 3E-7410 1 TEE-O-RING
2 3J-1907 1 SEAL-O-RING
I20 2 192-6775 1HOSEAS
21 2 202-1771 1 CONNECTOR
22 1 272-4144 1 GROMMET
I23 2 272-4227 1HOSEAS
I24 1 292-7147 1HOSEAS
25 2 292-7151 1 SUPPORT AS
Y26 2 297-0685 1 VALVE GP-SOLENOID & PRESS REDC 750
27 1 302-3112 1 SUPPORT AS
28 2 148-8336 1 CONNECTOR AS
2 3J-1907 1 SEAL-O-RING
2 6V-8397 1 SEAL-O-RING
2 6V-8636 1 CONNECTOR
29 2 148-8378 7 ELBOW AS
(EACH INCLUDES)
2 3J-1907 1 SEAL-O-RING
2 6V-8397 1 SEAL-O-RING
2 6V-8724 1 ELBOW
30 2 148-8407 1PLUGAS
2 3J-1907 1 SEAL-O-RING
2 9S-4191 1 PLUG-O-RING
31 2 148-8435 1TEEAS
2 3J-1907 1 SEAL-O-RING
2 6V-8397 2 SEAL-O-RING
2 6V-8781 1 TEE-FACE SEAL
32 2 150-3036 1 ELBOW AS
2 3J-1907 1 SEAL-O-RING
SEBP4861-02 1of3 HYDRAULIC SYSTEM 587
