CAT 315 Part Manual Page 300

Part Manual
POWER TRAIN
210-3529 DRIVE
GP-FINAL
S/N: CJN1 -UP
PART OF 165-577
7, 197-7178 DRIVE GP-FINAL
ALSO AN ATTACHME
NT
SMCS-4050 i02194733
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 165-5785 1 SPACER
B2 1 096-1773 1 SHIM (0.15-MM THK)
B1096-1774 1 SHIM (0.3-MM TH
K)
B1096-1775 1 SHIM (0.4-MM THK)
B1096-1776 1 SHIM (0.5-MM THK)
B1096-1777 1 SHIM (0.6-MM THK
)
B1096-1778 1 SHIM (0.7-MM THK)
B1096-1779 1 SHIM (0.8-MM THK)
B1096-1780 1 SHIM (1-MM THK)
B1096-1781 1 SHIM (1.6-MM THK)
11 1 227-6034 16 BOLT-FLANGE HEAD (M16X2X60-MM)
12 1 165-5786 3 SHAFT
13 1 094-1542 6 BEARING-ROLLER
14 1 165-5787 3 GEAR-PLANETARY
M15 1 094-1528 6 WASHER (53X84X1-
MM THK)
16 1 095-0891 6 PIN-SPRING
17 1 165-5788 3 GEAR-PLANETARY
18 1 094-0616 3 BEARING AS-ROLLER
19 1 3E-2338 2 PLUG-PIPE
20 1 7M-8485 2 SEAL-O-RING
21 1 165-5790 1 COVER
22 1 7Y-0225 3 SHAFT-PLANETARY
23 1 094-0611 6 WASHER (47.3X76X1-MM THK)
24 1 094-0580 1 PLATE (10-MM THK)
25 1 165-5792 1 GEAR-SUN
26 1 165-5793 1 GEAR-SUN
27 1 165-5794 1 SPACER
28 1 165-5795 1 CARRIER
M29 1 8T-7929 16 BOLT (M12X1.75X180-MM)
30 1 8T-4223 16 WASHER-HARD (13.5X
25.5X3-MM THK)
31 1 095-1299 3 DOWEL
32 1 165-3892 1 GEAR-RING
33 1 165-5796 1 CARRIER
34 1 165-5797 1 GEAR
35 1 165-5800 1 WASHER
36 1 210-3530 1 HOUSING
37 1 114-1539 4 PIN-DOWEL
38 1 168-8451 2 BALL BEARING
39 1 210-3531 1 HOUSING-MOTOR
40 1 114-1497 1 SEAL GP-DUO-CONE
B41 1 1U-8846 SEALANT-GASKET
B-USE AS REQUIRED
M-METRIC PART
270 POWER TRAIN 1of2 SEBP 4861-02
